Compact System
Busbar fuse material
2010 CA08103002Z-EN
www.eaton.comSASY
16/27
SASYBusbar fusematerial
Poles Rated opera-
tional current
Adapter
width
For use with
Copper
factor
2)
Part no.
Article no.
Price
See price
list
Std. pack
I
e
A
mm
Component adapters for circuit-breakers and switch-disconnectors
For surface mounting on flat copper busbars 12 – 30 x 5 – 10, double T and triple T profile
Rated operating voltage U
e
: 690 V
• Temperature-resistant up to 120 °C
• Self-extinguishing to UL 94
• Creepage resistance CTI 200
3 pole 160
90
NZM1,
PN1,
N(S)1
0.23
NZM1-XAD160
1)2)
104554
1 off
Poles Spacing
between
busbar
centers
Rated
operational
current
Max. fuse
link
Size
For use
with
Part no.
Article no.
Price
See
price list
Std. pack
I
e
500 V 690 V
mm
A
A A
LV h.b.c. fuse switch-disconnectors
For surface
mounting on
busbars
3 pole 60
100
100 100 NH00(0)
(max.
21 mm
width)
–
FCFSDNH000BBC60-3
4)
139533
1 off
Rated opera-
tional current
Rated operational
voltage
Size
Width For use
with
Part no.
Article no.
Price
See
price list
Std. pack
I
e
U
e
A
V AC
mm
D busbar mounting fuse devices
Basic units
Latch mechanism
for push-fitting on
busbar.
Gage ring
63
400
E18 D02 36
12 x 5/10
FCFBD02BBC60-3-36
3)
139532
6 off
Notes
1)
For switches with standard box terminal connection.
Connection to the system at top using supplied connection cable.
In conjunction with IP2X protection against contact with a finger
Enhanced contact protection on the switch output end possible.
Latch fitting to busbar using combination fixing base
Combination fixing base for adjustment to 5 and 10 mm rail thickness, terminal capacity 6 x 9 x 0.8.
Rated short-circuit switching capacity 35 kA at 480 V.
Busbar must be de-energized for mounting.
2)
Calculation of material surcharge￫hapter 23
3)
A complete and functional fuse element consists of the basic unit
•
Fuse link
￫Page 19/47
•
Fuse adapter
￫Page 19/47
•
Screw cap
￫Page 19/47
4)
LV h.b.c. fuse links
￫Page 19/53
Information relevant for export to North America
Product Standards
UL508A; CSA-C22.2 No. 14; IEC 60439-1; CE marking
UL File No.
E300273
UL CCN
NMTR, NMTR7
CSA File No.
236217
CSA Class No.
3211-37
NA Certification
UL Listed, CSA certified
Conditions of Acceptability Refer to approbation report
Suitable for
Feeder circuits
Max. Voltage Rating
600 V AC
NZM1-XAD, FCF...
HPL16027EN
