185 mm system
System for flat and profiled busbars
2010 CA08103002Z-EN
www.eaton.comSASY
16/31
Poles Rated opera-
tional current
For use with
Cu factor
Part no.
Article no.
Price
See price
list
Std. pack
I
e
A
Profiled busbars
E-CU double T profile busbar
Tinned,
cross-section 500 mm
2
,
2400 mm long.
–
1250
For supports
BBS-3/PR,
BBS-1/PR,
BBS-3/FL-185
CU-BAR-500/T
1)
107166
32 off
Tinned,
cross-section 720 mm
2
,
2400 mm long.
–
1600
For supports
BBS-3/PR,
BBS-1/PR,
BBS-3/FL-185
CU-BAR-720/T
1)
107167
32 off
E-CU triple T profiled busbars
Tinned,
cross-section1140mm
2
,
2400 mm long.
–
2500
For supports
BBS-3/FL-185,
KSX-3….
CU-BAR-1140/T
107168
10 off
Busbar shrouds
• Silicone-free, chlorine-free
• Temperature-resistant up to 110 °C
• Self-extinguishing to UL 94
1000 mm long.
–
–
12 x 10
15 x 10
20 x 10
25 x 10
30 x 10
BBC-FL10
107174
10 off
1000 mm long.
–
–
For double T
profile
BBC-CU-BAR/PR
107175
5 off
Notes
1)
Current load ￫
Page 16/39
Calculation of material surcharge￫Chapter 23
Information relevant for export to North America
Product Standards
UL508A; CSA-C22.2 No. 14; IEC 60439-1;
CE marking
UL File No.
E300273
UL CCN
NMTR, NMTR7
CSA File No.
236217
CSA Class No.
3211-37
NA Certification
UL Listed, CSA certified
Conditions of Acceptability
Refer to approbation report
Suitable for
Feeder circuits
Max. Voltage Rating
600 V AC
CU-BAR..., BBC...
