185 mm system
Terminals and connectors
2010 CA08103002Z-EN
SASY 16/37
Plate terminals
– 50 630 – All 10 mm thick flat
busbars
PK900
138378
3 off
Width For use with Copper
factor1)
Part no.
Article no.
Price
See price
list
Std. pack
mm
End-to-end busbar onnectors
For hole-less connection of identical busbars.
For the same flat copper bars.
Rated operating current 630 A
System spacing 100 - 110 mm.
Max. permissible busbar offset 1 mm.
150 12 x 5/10
15 x 5/10
20 x 5/10
BBT-CU12-20X5/10-150
107200
3 off
System spacing 50 - 60 mm.
Max. permissible busbar offset 5 mm.
95 BBT-CU20-30X5/10-95
107201
3 off
System spacing 100 - 110 mm.
Max. permissible busbar offset 5 mm.
150 BBT-CU20-30X5/10-150
107202
3 off
For differing and same double T profile busbars.
Rated operating current 1600 A
System spacing 9 - 20 mm.
Max. permissible busbar offset 2 mm.
50 Double T
profile
BBT-CU-BAR500/720-50
107203
6 off
System spacing 100 - 110 mm.
Max. permissible busbar offset 5 mm.
150 BBT-CU-BAR500/720-150
107204
3 off
Notes 1) Calculation of material surcharge￫Chapter 23
Terminal
area
W × H
Width Rated
operating
current
Ie
Terminal capacity For use with Part no.
Article no.
Price
See price
list
Std. pack
⊙ Round conductor, solid
 Round conductor, flexible, with
correctly crimped ferrule
 Round conductor, stranded
 Sectoral conductor, solid
 Sectoral conductor,, stranded
Copper strip
▃Copper bar
mm mm A mm
PK..., BBT-CU... HPL16037EN
