Busbar system
LV h.b.c. fuse switch-disconnectors
2010 CA08103002Z-EN
SASY 16/43
SASYLVh.b.c. fuse switch-disconnectors
LTS-100/C00/3-R GST…00-160-40-
60-AOU
GST1-AO(AU) GST2-AO(AU) GST3-AO(AU)
General
Standards IEC/EN 60947-3
Climatic proofing Damp heat, constant, to IEC 60068-2-78; Damp heat, cyclical to IEC 60068-2-30
Ambient temperature °C -25 - +55 -25 - +55 -25 - +55 -25 - +55 -25 - +55
Installation altitude m Max. 2000 Max. 2000 Max. 2000 Max. 2000 Max. 2000
Distance between busbar centers m 60 60 60 60 60
Mounting position Vertical or horizontal
Overvoltage category/pollution degree III/3 III/3 III/3 III/3 III/3
Touch protection at the front
Operational status IP20 IP20 IP20 IP20 IP20
Front cover open IP10 IP10 IP10 IP10 IP10
Direction of incoming supply Any
Lifespan, mechanical Operations 1700 1700 1700 1700 1700
Weight kg 0.57 0.93 4.4 5.3 6.6
Contacts
Rated operational current
500 V AC/220 V DC Ie A 100 160 250 400 630
690 V AC / 440 V DC Ie A – 100 200 315 500
Rated frequency Hz 40 - 60 40 - 60 40 - 60 40 - 60 40 - 60
Rated conditional short-circuit current
AC Iq kArms 50 50 50 50 50
DC Iq kArms 25 25 25 25 25
Utilization category AC-22B
Rated making capacity
500 V AC A 300 480 750 1200 1890
690 V AC A – 300 600 945 1500
Rated breaking capacity
500 V AC A 300 480 750 1200 1890
690 V AC A – 300 600 945 1500
Utilization category DC-21B
Rated making capacity
220 V DC/440 V DC A 400 150 300 475 750
Rated breaking capacity
220 V DC/440 V DC A 400 150 300 475 750
Lifespan, electrical Operations 300 300 200 200 200
Heat dissipation at Ith, without fuse link
500 V AC W 11.5 6.9 12.9 27 52
690 V AC W – 2.7 8.3 16.7 32.8
220 V DC W 7.7 4.6 8.6 18 34.7
440 V DC W – 1.8 5.5 11.2 21.8
Rated insulation voltage Ui V 500 750 750 750 750
Max. fuse link
Construction size NH000 NH00 NH1 NH2 NH3
Max. rated operational current, gL/gG A 100 160 250 400 630
Max. permissible heat dissipation fuse link Pv W 7.5 12 23 34 48
Terminal capacities
Box terminal
Stranded mm2 1.5 - 50 1.5 - 70 – – –
Copper strip Number of segments x width x
thickness
mm 6 x 9 x 0.8 6 x 9 x 0.8 – – –
Flange connection
Bolt diameter d mm – – M10 M10 M10
Cable lug mm2 – – 1 x 25 - 100 1 x 25 - 100 1 x 25 - 100
Flat rail max. mm – – 30 x 10 30 x 10 30 x 10
Box terminal
Stranded copper mm2 – – 25 - 150 25 - 240 25 - 300
Copper strip Number of segments x width x
thickness
mm – – 6 x 16 x 0.8 10 x 16 x 0.8 11 x 21 x 1
Cable clamp
Stranded aluminium/copper mm2 – – 70 - 150 120 - 240 120 - 300
Double cable clamp
Stranded aluminium/copper mm2 – – 2 x (70 - 95) 2 x (120 - 150) 2 x (120 - 240)
LTS-100..., GST...
