Busbar system
LV h.b.c. fuse switches accessories for LV h.b.c. fuse switch-disconnectors
2010 CA08103002Z-EN
www.eaton.comSASY
16/45
SASYLVh.b.c. fuse switchesaccessories for LVh.b.c. fuse switch-disconnectors
NH-SLS-…-SI
General
Standards
IEC/EN 60255,
VDE 0435 part 303
Climatic proofing
Damp heat, constant, to IEC 60068-2-78
Damp heat, cyclic, to IEC 60068-2-30
Ambient temperature
°C
-5 - +40
Installation altitude
m Max. 2000
Contacts
Rated operating voltage
U
e
V
3 x 400 AC
Voltage range
V AC 0.8 … 1.1 x U
e
Rated frequency
f
Hz
50 - 60
Intrinsic consumption per phase (conductor)
VA 2 (L2/L3)
Rated insulation voltage
U
i
V
400
Overvoltage category
III
Rated operating mode
Continuous operation
Rated impulse withstand voltage
U
imp
kV
4
Relay contacts
Standards
EN 60947-5-1
Rated voltage
U
e
V AC 250
Conventional thermal current
I
th
A
4
Utilization category AC-15
Rated operating voltage
U
e
V AC 230
Rated operational current
AC-15 at 230 V
I
e
A
1
Lifespan, electrical
Operations
1.5 x 10
5
Lifespan, mechanical
Operations
> 10
8
Max. admissible back-up fuse
A gL
4
Terminal capacities
Box terminal
Solid
mm
2
2 x 2.5
Flexible
mm
2
2 x 1.5
Response/reset time
ms
< 500
GST…-DSI
Electrical data
Standards
IEC/EN 60255,
VDE 0435 part 303
Rated operating voltage
U
e
V AC 3 x 400 - 690
Voltage range
V AC 0.9 … 1.1 x U
e
Rated frequency
f
Hz
50 - 60
Energy consumption
P
VA 1.5 (L2/L3)
Rated insulation voltage
U
i
V
690
Overvoltage category
III
Rated impulse withstand voltage
U
imp
kV
6
Rated voltage
U
e
V AC 250
Rated operational current
I
e
A
8 A DC
Inrush current
A
≦ 15
Minimum switching load
5 V AC/DC, 300 mW, 5mA
Max. switching power
AC 1
VA 2000
250 V AC 15
VA 400
250 V AC 3
W 300
Lifespan, electrical
Operations
80 x 10
3
(AC 1)
Max. admissible back-up fuse
4 A gL/gG / PLSM-B4…-HS
Mechanical data
Terminals
Lift terminals
Terminal cross-section, flexible
mm
2
0.25 - 1.5
Tightening torque of terminal screws
Nm 0.5 - 0.6
Lifespan, mechanical
Operations x 10
6
> 10
Response/reset time
ms
< 500
Degree of protection
IP20
Temperature range
°C
-10 … +55
Pollution degree
3
Terminal capacity
mm²
0.25 - 1.5
NH-SLS-...-SI, GST...-DSI
