16/48 Busbar system
LV h.b.c. fuse switch-disconnector, D-type fuse base
2010 CA08103002Z-EN
www.eaton.comSASY
SASYD-type fusebases, LVh.b.c. fuse switch-disconnector
FCFSDNH000BBC60-3
General
Standards
IEC/EN 60947-3
Climatic proofing
Damp heat, constant, to IEC 60068-2-78
Damp heat, cyclic, to IEC 60068-2-30
Ambient temperature
°C
Installation altitude
m
Max. 2000
Mounting position
Vertical or horizontal
Overvoltage category/pollution degree
III/3
Contact protection shroud
at the front
Operational status
IP20
Front cover open
IP10
Direction of incoming supply
any
Lifespan, mechanical
Operations
1700
Weight
kg
0.93
Contacts
Rated operational current
690 V AC / 440 V DC I
e
A
100
Rated frequency
f
Hz
40 - 60
Rated conditional short-circuit current
690 V AC
I
q
kA
rms
50
440 V DC
I
q
kA
rms
25
Utilization category AC-22B Rated making capacity
A 100
Rated breaking capacity
A 100
Utilization category DC-21B Rated making capacity
A 80
Rated breaking capacity
A 80
Lifespan, electrical
Operations
300
Heat dissipation at I
th
,
without fuse link
690 V AC
W W 2.7
440 V DC
W 1.8
Rated insulation voltage
U
imp
V
750
Max. fuse link
Construction size
Number of segments x width x thickness
NH00(0) (max. 21 mm width)
Max. rated operational current gL/gG
A 100
Max. permissible heat dissipation of fuse link
P
v
W 9
Terminal capacity
Box terminal
Flexible
mm
2
2.5 - 50
Flexible with ferrule
mm
2
1.5 - 50 (ferrule with maximum cross-section may not be possible)
Solid
mm
2
1.5 - 10
Stranded
mm
2
16 - 50
Copper strip
Number of segments x width x thickness
mm 6 x 9 x 0.8; 9 x 9 x 0.8
FCFBD02BBC60-3-36
General
Standards
Type according to IEC/EN 60269-1, VDE 0636 Part 301
Climatic proofing
Damp heat, constant, to IEC 60068-2-78
Damp heat, cyclic, to IEC 60068-2-30
Ambient temperature
°C
-25 - +55
Mounting position
Vertical or horizontal
Contacts
Poles
3
Rated operational voltage
U
e
V AC 400 V AC
Rated short-circuit current, tested with fuse links
I
q
kA
rms
50
Rated frequency
f
Hz
40 - 60
Rated operational current
I
e
A 63
Conventional thermal current with fuse links
I
th
A 63
Rated operating mode
Uninterrupted operation
Overvoltage category
IV
Rated impulse withstand voltage
U
imp
kV 6
Current heat dissipation per contact at I
e
W 0.5
Heat dissipation per contact with fuse link at I
e
W 1.5
Max. permissible heat dissipation of fuse links
P
v
W 5.5
Mechanical data
Enclosure width
mm 160
Built-in width
mm 36
Weight
g
g
130
Electric thread
E18
Degree of protection
Integrated
IP20
Terminals
Lift terminals
Terminal capacity
Solid
mm
2
1.5 - 25
Pollution degree
3
FCFS...-3, FCFB...-3-36
