Eaton Industrial Switchgear - XEnergy XPole Energy distribution, switching and protection

33 / 543

2010 CA08103002Z-EN
Busbar system
185 mm system
SASY 16/29
LV h.b.c. fuse switches 250 up to 630 A 1
Spacing between busbar centers
185 mm.
Prepared for current transformer.
Top or bottom outgoer possible.
With/without electronic fuse
monitoring.
￫Page 16/32
LV h.b.c. fuse switches 160 A 2
Spacing between busbar centers
100 mm.
Adaptable for 185 mm system.
With/without electronic fuse
monitoring.
Top or bottom outgoer possible.
￫Page 16/32
Busbar supports 3
Spacing between busbar centers
185 mm.
Hole-less mounting of 30, 40, 50, to
120 x 10 mm flat busbars, double T
and triple T profiled busbars.
￫Page 16/31
Adapters 4
Adapts NH00 fuse combination units
to the 185 mm system.
Single or double adapters.
Prepared for current transformer.
￫Page 16/33
Current transformer 5
Can be retrofitted at any time with all
fuse combination units.
No additional space required, simply
swing in.
￫Page 16/33
Disconnecting blades 6
Can be used instead of LV h.b.c. fuse
links.
Full contact blades.
LV h.b.c. fuse links 7
High breaking capacity 120 kA.
Fuse links NH00, NH1, NH2 and NH3
up to 630 A.
￫Page 19/53
Profile terminals 8
Safe connection of flat copper
busbars or multi-layer copper strip
to profiled busbars.
8 different construction sizes from
750 to 3600 mm2 terminal area.
￫Page 16/35
Expansion terminals 9
For fitting to busbars without drilling.
Cables can be inserted from the top
simply and quickly.
￫Page 16/34
Universal conductor terminals 10
With integrated retaining spring.
Captive fixing screw.
Suitable for all copper, flat and
profiled busbars.
￫Page 16/36
End-to-end busbar connectors 11
For interconnecting busbar systems.
For flat and profiled busbars.
￫Page 16/37
Flat busbars, profiled busbars 12
Profiled busbars with cross-sections
500, 720 and 1140 mm², and flat
copper busbars up to 30 x 10 mm.
Tin-plated copper busbars cut time
needed to prepare contact points.
Flat busbars
￫Page 16/24
Profiled busbars
￫Page 16/31
