Single-phase control transformers
2010
CA08103002Z-EN
www.eaton.com15/5
Single-phasecontrol transformers
Rated output
Short-time rating
Part no.
Article no.
Price
See price list
Std. pack
Notes
kVA
kVA
Single-phase control transformers
IEC/EN 61558-2-2
VDE 0570 Part 2-2
Rated input voltage 100 – 690 ± 5 % V
Rated output voltage 12 – 250 V
0.06
0.095
STN0.06(*/*)
204938
1
off
Ordering example
When ordering, the part number must include the
following details:
STN0, 1(*/*)
First asterisk ≙ rated input voltage
Second asterisk ≙ rated output voltage
•
Desired part no. STN0, 1
•
Desired rated input voltage 200 V
•
Desired rated output voltage 18.5 V
The correct part no. is
STN0. 1(200/18.5)
Transformer-protective circuit-breakers
PKZMO-…-T￫Page 7/6
0.1
0.16
STN0.1(*/*)
204939
0.16
0.32
STN0.16(*/*)
204944
0.2
0.38
STN0.2(*/*)
204950
0.25
0.44
STN0.25(*/*)
204979
0.315
0.6
STN0.315(*/*)
204981
0.4
0.62
STN0.4(*/*)
204983
0.5
0.88
STN0.5(*/*)
204985
0.63
1.51
STN0.63(*/*)
204987
0.8
2.25
STN0.8(*/*)
204989
1
3.28
STN1.0(*/*)
204991
1.3
4.8
STN1.3(*/*)
204993
1.6
3.98
STN1.6(*/*)
204994
2
5.75
STN2.0(*/*)
204995
2.5
7.24
STN2.5(*/*)
204996
3
8.36
STN3.0(*/*)
204997
4
12.2
STN4.0(*/*)
204998
Notes
Information relevant for export to North America
Product Standards
UL 506; UL5085-1; UL 5085-2; CSA-C22.2 No. 66; CSA-C22.2 No. 66.1-06;
CSA-C22.2 No. 66.2-06; IEC/EN 61558-2-2; CE marking
UL File No.
E167225
UL CCN
XPTQ2, XPTQ8
CSA File No.
UL report applies to both US and Canada
CSA Class No.
–
NA Certification
UL Recognized, certified by UL for use in Canada
Suitable for
Branch circuits
Max. Voltage Rating
600
V AC
Degree of Protection
IEC: IP00, UL/CSA Type: -
STN
HPL15005EN
