8 / 23
15/4
Transformers
Single-phase control transformers with standard voltages
2010
CA08103002Z-EN
www.eaton.comSingle-phasecontrol transformerswith standard voltages
Ordering
Preferred voltage 400/230 V
Preferred voltage 400/24 V
Preferred voltage 230/24 V
Rated output
kVA
Short-time rating
kVA
Part no.
Article no.
Price
See price
list
Part no.
Article no.
Price
See price
list
Part no.
Article no.
Price
See price
list
Std. pack
Single-phase control transformers
with standard voltages
IEC/EN 61558-2-2
VDE 0570 Part 2-2
Rated input voltage 230 ± 5 % V ,
400
± 5 % V
Rated output voltage 24 V , 230 V
0.06
0.095
STN0.06(400/230)
204936
STN0.06(400/24)
204937
STN0.06(230/24)
204935
1
off
0.1
0.16
STN0.1(400/230)
204942
STN0.1(400/24)
204943
STN0.1(230/24)
204941
0.16
0.32
STN0.16(400/230)
204948
STN0.16(400/24)
204949
STN0.16(230/24)
204947
0.2
0.38
STN0.2(400/230)
204977
STN0.2(400/24)
204978
STN0.2(230/24)
204976
0.25
0.44
STN0.25(400/230)
204980
STN0.25(400/24)
221509
STN0.25(230/24)
221508
0.315
0.6
STN0.315(400/230)
204982
STN0.315(400/24)
221511
STN0.315(230/24)
221510
0.4
0.62
STN0.4(400/230)
204984
STN0.4(400/24)
221514
STN0.4(230/24)
221513
0.5
0.88
STN0.5(400/230)
204986
STN0.5(400/24)
221516
STN0.5(230/24)
221515
0.63
1.51
STN0.63(400/230)
204988
STN0.63(400/24)
221518
STN0.63(230/24)
221517
0.8
2.25
STN0.8(400/230)
204990
STN0.8(400/24)
221520
STN0.8(230/24)
221519
1
3.28
STN1.0(400/230)
204992
STN1.0(400/24)
221522
STN1.0(230/24)
221521
1.3
4.8
STN1.3(400/230)
221523
1.6
3.98
STN1.6(400/230)
221524
2
5.75
STN2.0(400/230)
221525
2.5
7.24
STN2.5(400/230)
221526
3
8.36
STN3.0(400/230)
221527
4
12.2
STN4.0(400/230)
221528
Notes
Information relevant for export to North America
Product Standards
UL 506; UL5085-1; UL 5085-2; CSA-C22.2 No. 66; CSA-C22.2 No. 66.1-06; CSA-C22.2 No. 66.2-06;
IEC/EN 61558-2-2; CE marking
UL File No.
E167225
UL CCN
XPTQ2, XPTQ8
CSA File No.
UL report applies to both US and Canada
CSA Class No.
–
NA Certification
UL Recognized, certified by UL for use in Canada
Suitable for
Branch circuits
Max. Voltage Rating
600
V AC
Degree of Protection
IEC: IP00, UL/CSA Type: -
STN
