Single-phasecontrol, isolatingand safety transformers
Rated output
Short-time rating
Part no.
Article no.
Price
See price
list
Std. pack
Notes
kVA
kVA
Single-phase control, isolating and
safety transformers
IEC/EN 61558-2-2/2-4/2-6
VDE 0570 Part 2-2, Part 2-6 (safety trans-
formers), Part 2-4 (isolating transformers)
Rated input voltage 50 – 950 ± 5 % V
Rated output voltage 12 – 1000 V
0.06
0.13
STZ0.06(*/*)
914761
1
off
•
Transformers with rated output voltages ≦ 50 V can be used as
safety transformers to IEC/EN 61558.
Ordering example
When ordering, the part number must include the following
details:
STZ0.06(*/*)
First asterisk ≙ rated input voltage
Second asterisk ≙ rated output voltage
•
Desired part no. STZ0.06
•
Desired rated input voltage 230 V
•
Desired rated output voltage 12 V
The correct type reference is
STZ0.06(230/12)
Caution!
Standard voltages 400/230 V, 400/24 V,230/230 V, 230/24 V are only
supplied as STI￫Page 15/6 if other suffixes, e.g. shield winding,
are not ordered.
Accessories ￫Page 15/10
0.1
0.24
STZ0.1(*/*)
914762
0.16
0.36
STZ0.16(*/*)
914763
0.2
0.44
STZ0.2(*/*)
914764
0.25
0.6
STZ0.25(*/*)
914765
0.315
0.75
STZ0.315(*/*)
914766
0.4
1.1
STZ0.4(*/*)
914767
0.5
1.6
STZ0.5(*/*)
914768
0.63
1.7
STZ0.63(*/*)
914769
0.8
2
STZ0.8(*/*)
914770
1
2.8
STZ1.0(*/*)
914771
1.3
3.7
STZ1.3(*/*)
914772
1.6
5.5
STZ1.6(*/*)
914773
2
7
STZ2.0(*/*)
914774
2.5
9
STZ2.5(*/*)
914775
3
11.5
STZ3.0(*/*)
914776
4
15
STZ4.0(*/*)
914777
5.3
13
STZ5.3(*/*)
201060
8.3
21
STZ8.3(*/*)
201062
13.3
34
STZ13.3(*/*)
201064
Notes
Information relevant for export to North America
Product Standards
UL 506; UL5085-1; UL 5085-2; CSA-C22.2 No. 66; CSA-C22.2 No. 66.1-06; CSA-C22.2
No. 66.2-06; IEC/EN 61558-2-2; CE marking
UL File No.
E167225
UL CCN
XPTQ2, XPTQ8
CSA File No.
UL report applies to both US and Canada
CSA Class No.
–
NA Certification
UL Recognized, certified by UL for use in Canada
Suitable for
Branch circuits
Max. Voltage Rating
600
V AC
Degree of Protection
IEC: IP00, UL/CSA Type: -
STZ
HPL15007EN
