15/10 Transformers
Accessories
2010 CA08103002Z-EN
Accessories
For use with Part no. suffix
Article no. for
ordering only
with basic unit
Price
See price list
Std. pack Notes Information relevant for export to
North America
IP23 enclosures
STZ0.06 … STZ0.16 +IP23/01
200618
1 off Enclosure can be used with primary
or secondary voltages >110 V.
For lower voltages, please enquire.
STZ0.2 … STZ0.5 +IP23/02
200623
STZ0.63 … STZ1.3 +IP23/03
200624
STZ1.6 … STZ2.0 +IP23/04
226100
STZ5.3 … STZ8.3 +IP23/05
200648
STZ13.3 +IP23/06
200649
STZ2.5 … STZ4.0
DTZ1.0 … DTZ2.0
+IP23/32A
200763
Enclosure can be used with primary
or secondary voltages from 42 V to
max. 1000 V incl. taps. DTZ0.1 … DTZ0.16 +IP23/30
200706
DTZ0.25 … DTZ0.63 +IP23/31
200753
DTZ2.5 … DTZ6.3 +IP23/33
200754
DTZ8.0 … DTZ25 +IP23/34
200755
Shielding winding
STZ0.06 … STZ1.6 +W1.8
082270
1 off Shielding winding means additional
shielding between the primary and
secondary winding.
UL/CSA approval not required
STZ2.0 … STZ13.3 +W4.0
082271
DTZ0.1… DTZ6.3 +W6.0
082274
DTZ8.0 … DTZ20 +W20.0
082275
Primary current For use with Type
Article no.
when ordered
separately
Price
See price list
Type suffix
Article no. for
ordering only
with basic unit
Price
See price
list
Std.
pack
Notes
IN
A
Inrush current limiters
For single-phase transformers
1 STI
STZ
EEB1
226102
+EEB1
226101
1 off Primary current: from the transformer
rating plate or by calculation
Single-phase: IN = SN /(UNprim x η)
Three-phase: IN = SN /(√3 UNprim x η)
SN = rated transformer output
UNprim = Transformer´s primary rated
voltage
η = efficiency (from the technical data
table)
2 EEB2
226104
+EEB2
226103
3 EEB3
226106
+EEB3
226105
+IP23..., +W..., EEB..., +EEB... HPL15010EN
