Transformers
Single-phase control, isolating and safety transformers
2010
CA08103002Z-EN
www.eaton.comSingle-phasecontrol, isolatingand safety transformers
Standard voltage
400/230
V
Standard voltage
400/24
V
Standard voltage
230/230
V
Standard voltage
230/24
V
Price
See
price list
Rated output
Short-time rating
Part no.
Article no.
Part no.
Article no.
Part no.
Article no.
Part no.
Article no.
Std. pack
kVA
kVA
Single-phase control, isolating and safety
transformers with standard voltages
IEC/EN 61558-2-2/2-4/2-6
VDE 0570 Part 2-2, Part 2-6 (safety transformers),
Part 2-4 (isolating transformers)
Rated input voltage 230 ± 5 % V, 400 ± 5 % V
Rated output voltage 24 , 230 V
0.06
0.13
STI0.06(400/230)
029975
STI0.06(400/24)
029971
STI0.06(230/230)
029968
STI0.06(230/24)
029977
1
off
0.1
0.24
STI0.1(400/230)
046630
STI0.1(400/24)
046631
STI0.1(230/230)
029976
STI0.1(230/24)
046629
0.16
0.36
STI0.16(400/230)
046633
STI0.16(400/24)
046634
STI0.16(230/230)
035247
STI0.16(230/24)
046632
0.2
0.44
STI0.2(400/230)
046636
STI0.2(400/24)
046637
STI0.2(230/230)
035248
STI0.2(230/24)
046635
0.25
0.6
STI0.25(400/230)
046638
STI0.25(400/24)
035249
STI0.25(230/230)
036400
STI0.25(230/24)
035262
0.315
0.75
STI0.315(400/230)
046639
STI0.315(400/24)
035250
STI0.315(230/230)
040641
STI0.315(230/24)
036392
0.4
1.1
STI0.4(400/230)
046640
STI0.4(400/24)
035251
STI0.4(230/230)
040642
STI0.4(230/24)
036393
0.5
1.6
STI0.5(400/230)
046641
STI0.5(400/24)
035252
STI0.5(230/230)
040643
STI0.5(230/24)
036394
0.63
1.7
STI0.63(400/230)
046883
STI0.63(400/24)
035253
STI0.63(230/230)
040644
STI0.63(230/24)
036395
0.8
2
STI0.8(400/230)
046889
STI0.8(400/24)
035254
STI0.8(230/230)
026641
STI0.8(230/24)
036396
1
2.8
STI1.0(400/230)
046895
STI1.0(400/24)
035255
STI1.0(230/230)
026642
STI1.0(230/24)
036397
1.3
3.7
STI1.3(400/230)
046918
STI1.3(230/230)
035256
1.6
5.5
STI1.6(400/230)
046952
STI1.6(230/230)
035257
2
7
STI2.0(400/230)
035258
STI2.0(230/230)
036398
2.5
9
STI2.5(400/230)
035259
STI2.5(230/230)
036399
3
11.5
STI3.0(400/230)
035260
4
15
STI4.0(400/230)
035261
Notes
Information relevant for export to North America
Product Standards
UL 506; UL5085-1; UL 5085-2; CSA-C22.2 No. 66; CSA-C22.2 No. 66.1-06;
CSA-C22.2 No. 66.2-06; IEC/EN 61558-2-2; CE marking
UL File No.
E167225
UL CCN
XPTQ2, XPTQ8
CSA File No.
UL report applies to both US and Canada
CSA Class No.
–
NA Certification
UL Recognized, certified by UL for use in Canada
Suitable for
Branch circuits
Max. Voltage Rating
600
V AC
Degree of Protection
IEC: IP00, UL/CSA Type: -
STI
HPL15006EN
