10/22 Frequency inverters
Key to part numbers
2010 CA08103002Z-EN
Key topartnumbers
Series MMX
MMX32AA1D7F0-0 (example)
MMX 3 2 A A 1D7 F 0 - 0
MMX 1 2 A A Variable code F 0 - 0
3 4 N
MMX = Product family M-Max™
Number of phases
1 = Single-phase mains supply
3 = Three-phase mains supply
Voltage class
2 = 200 V (208 V -15 % to 240 V +10 %)
4 = 400 V (380 V -15 % to 480 V +10 %)
Version
A = Software version
Display unit
A = Display unit built-in
Rated operational current (in amperes)
xDy = x,y A (digital; e.g. 1D7 = 1.7 A)
0xy = xy A
Radio interference suppression filters
F = with integrated radio interference suppression filter (C2)
N = without radio interference suppression filter
Protection type
0 = IP20 = NEMA 0
Optional module
0 = no module built in
Series HMX
HMX34AG3D421-B (example)
HMX 3 4 A G 3D4 2 1 - B
HMX 3 2 A G Variable
code
2 1 - B
4 2
HMX = Product family H-Max™
Number of phases
3 = Three-phase mains supply
Voltage class
2 = 200 V (208 V -15 % to 240 V +10 %)
4 = 400 V (380 V -15 % to 480 V +10 %)
Version
A = Software version
Display unit
G = Graphics
Rated operational current (in amperes)
xDy = x,y A (digital; e.g. 3D4 = 3.4 A)
xyz = xyz A
Radio interference suppression filter (built-in)
2 = C2
Protection type
1 = IP21 = NEMA 1
2 = IP54 = NEMA 2
Brake chopper
B = Built-in brake chopper
