Frequency inverters
Accessories for M-Max™ and H-Max™
2010
CA08103002Z-EN
www.eaton.comAccessories forM-Max™andH-Max™
Accessories forH-Max™
Part no.
Article no.
Price
See price
list
Std. pack
Notes
Interface cards
For use with MMX…
PC connection (USB/RJ45) for the frequency inverters of M-Max series
•
With 3.2 m connection cable and interface converter
•
Data transfer with PC software and copy function (retentive memory)
between MMX... frequency inverters
MMX-COM-PC
121406
1
off
Mounting frame for XMX-NET... fieldbus interface cards
On M-Max™ frequency inverters
MMX-NET-XA
134510
1
off
Mounting frame for side
connection to M-Max™
frequency inverters
For use with MMX... und HMX...
Description
Part no.
Article no.
Price
See price
list
Std. pack
Notes
Fieldbus connection
CANopen
Connection through plug-in screw terminals
The interface card is slotted into the device.
XMX-NET-CO-A
134511
1
off
Mounting frame MMX-NET-XA
required for M-Max™
PROFIBUS-DP
(
Screw terminal)
Connection through plug-in screw terminals
The interface card is slotted into the device.
XMX-NET-PS-A
136556
PROFIBUS-DP
(
Sub D)
Connection through Sub-D plug
The interface card is slotted into the device.
XMX-NET-PD-A
136557
PROFINET
The interface card is slotted into the device.
XMX-NET-PN-A
138237
DeviceNet
The interface card is slotted into the device.
XMX-NET-DN-A
136558
LON
The interface card is slotted into the device.
XMX-NET-LO-A
138238
Plug-in modules
For use with HMX...
Digital I/O card 6 digital input (24 V DC)
6
digital outputs
(
transistor, 24 - 48 V DC)
24
V supply
XMX-IO-B1-A
138239
1
off
–
Relay/thermistor
card
1
relay (changeover contact, N/O/NC, 250 V, 2
A)
1
relay (normally open contact, N/O, 250 V, 2 A)
1
thermistor input
XMX-IO-B2-A
138240
–
Analog I/O card 1 analog input (0 -+ 10 V, 4 - 20 mA)
2
analog outputs (0 -+ 10 V, 4 - 20 mA)
XMX-IO-B4-A
138241
–
Relay card
3
relays(normallyopencontact,N/O,250 V,2A)
XMX-IO-B5-A
138242
–
PT100 card
3
PT 100 thermistor inputs
24
V supply
XMX-IO-B8-A
138243
–
Digital input/relay
card
1
relay (normally open contact, N/O, 250 V, 2 A)
5
digital inputs (42 - 240 V AC)
XMX-IO-B9-A
138244
–
Output card
1
relay (normally open contact, N/O, 250 V, 2 A)
1
digital output (transistor, 24 - 48 V DC)
1
analog output (0 -+ 10 V, 4 - 20 mA)
XMX-IO-BF-A
138245
–
MaxConnect
USB
RJ 45
COMM
ACDRIVE
ERROR
OK
BACK
RESET
LOC
REM
