9/54 DM4 soft starters
DM4 soft starters
2010 CA08103002Z-EN
DM4 soft starters
DM4-340-7K5 DM4-340-11K DM4-340-15K DM4-340-22K
General
Standards IEC/EN 60947-4-2
Approvals UL, cUL UL, cUL UL, cUL UL, cUL
Climatic proofing Damp heat, constant, according to IEC 60068-2-78;
Damp heat, cyclic, according to IEC 60068-2-30
Ambient temperature °C 0 - +40, to 60 with a reduction of I e of 2 % per °C
Ambient temperature storage °C -25 - 60 -25 - 60 -25 - 60 -25 - 60
Installation altitude m 0 - 1000, to 2000 m with a current reduction of 1 % per 100 m
Mounting position Vertical Vertical Vertical Vertical
Protection type IP20 IP20 IP20 IP20
Protection against direct contact Finger- and back-of-hand proof
Pollution degree 2 2 2 2
Power loss of rated operational current Ie W 50 63 91 120
Dimensions (W x H x D) mm 222 x 290 x 195 222 x 290 x 195 222 x 290 x 195 222 x 290 x 195
Weight kg 6.7 6.7 6.7 6.7
Main contacts
Rated operating voltage Ue V AC 230 - 460 230 - 460 230 - 460 230 - 460
Rated insulation voltage Ui V AC 460 460 460 460
Mains frequency Hz 50/60 50/60 50/60 50/60
Control section power supply UC V AC 110/230 110/230 110/230 110/230
Rated operational current
Motor load (AC-53) Ie A 16 23 30 44
Assigned motor rating
(standard connection)
230 V P kW 4 5.5 7.5 11
400V P kW 7.5 11 15 22
480 V P HP 10 15 20 30
Phase current
In-delta terminal type A 27 39 51 76
Assigned motor rating
(in-delta terminal type)
230 V kW 7.5 11 15 22
400 V kW 11 15 22 37
480 V HP 20 25 30 50
Overload cycle to IEC/EN 60947-4-2
AC-53a (without bypass) 16 A: AC-53a: 3-35:
99-10
23 A: AC-53a: 3-35:
99-10
30 A: AC-53a: 3-35:
99-10
44 A: AC-53a: 3-35:
99-10
Short-circuit rating
Type “1” of coordination PKZM0-16 PKZM0-25 PKZ2/ZM-32 NZM7-63N
Type “2” of coordination
additionally
20.282.20-40 20.282.20-80 20.282.20-80 20.282.20-125
DM4
