DM4 soft starters

DM4 soft starters

2010

CA08103002Z-EN

DM4 soft starters

DM4-340-110K

DM4-340-132K

DM4-340-160K

Terminal capacity

Power cables

Connection

M8 bolt for cable lug

Solid

mm

2

–

–

–

Flexible with ferrule

mm

2

–

–

–

Flexible with cable lug

mm

2

2

x (35 - 95)

2

x (35 - 95)

2

x (35 - 95)

Stranded

mm

2

–

–

–

Stranded with cable lug

mm

2

2

x (50 - 120)

2

x (50 - 120)

2

x (50 - 120)

Solid or stranded

AWG

2

x 1/0

2

x 250 MCM

2

x 1/0

2

x 250 MCM

2

x 1/0

2

x 250 MCM

Flat conductor

(

number of layers x width x thickness)

mm

2

x (6 x 16 x 0.8)

2

x (6 x 16 x 0.8)

2

x (6 x 16 x 0.8)

Busbar (width)

mm

2

x (20 x 6)

2

x (20 x 6)

2

x (20 x 6)

Tightening torque

Nm

12

12

12

Screwdriver (PZ: Pozidriv)

mm

0.6

x 3.5

0.6

x 3.5

0.6

x 3.5

Control cables

Solid

mm

2

1

x (0.75 - 2.5)

1

x (0.75 - 2.5)

1

x (0.75 - 2.5)

Flexible with ferrule

mm

2

1

x (0.75 - 2.5)

1

x (0.75 - 2.5)

1

x (0.75 - 2.5)

Stranded

mm

2

1

x (0.75 - 2.5)

1

x (0.75 - 2.5)

1

x (0.75 - 2.5)

Solid or stranded

AWG

22 - 12

22 - 12

22 - 12

Tightening torque

Nm

0.5

0.5

0.5

Screwdriver

mm

0.6

x 3.5

0.6

x 3.5

0.6

x 3.5

Control circuit

Current consumption

Digital inputs

24

V DC

mA

0.45

0.45

0.45

230

V AC

mA

4.5

4.5

4.5

Analog inputs

0 - 10

V

mA

1

1

1

Pick-up voltage

DC operated

V DC

24 - 230

24 - 230

24 - 230

AC operated

V AC

24 - 230

24 - 230

24 - 230

Drop-out voltage

DC operated

V DC

0 - 3

0 - 3

0 - 3

AC operated

V AC

0 - 3

0 - 3

0 - 3

Programmable relay outputs

Quantity

4

4

4

Max. voltage

V AC

250

250

250

Max. current AC-11

A

3

3

3

Programmable analog outputs

Quantity

2

2

2

Voltage range

V DC

0 - 10

0 - 10

0 - 10

Current carrying capacity

mA

10

10

10

Programmable analog inputs

Ref 1

V DC

0 - 10

0 - 10

0 - 10

Ref 2

mA

4 - 20

4 - 20

4 - 20

Soft start function

Ramp times

Acceleration time

s

1 - 255

1 - 255

1 - 255

Deceleration time

s

0 - 255

0 - 255

0 - 255

Start voltage

%

10 - 60

10 - 60

10 - 60

Voltage reduction at stop

%

0 - 100

0 - 100

0 - 100

Kick-start

Voltage

%

60 - 90

60 - 90

60 - 90

Duration

50

Hz

ms

100 - 400

100 - 400

100 - 400

60

Hz

ms

166 - 664

166 - 664

166 - 664

Current limitation

(0.5 - 8)

x I

e

(0.5 - 8)

x I

e

(0.5 - 8)

x I

e

DM4
