9/58 DM4 soft starters
DM4 soft starters
2010 CA08103002Z-EN
DM4 soft starters
DM4-340-110K DM4-340-132K DM4-340-160K
General
Standards IEC/EN 60947-4-2
Approvals UL, cUL UL, cUL UL, cUL
Climatic proofing Damp heat, constant, according to IEC 60068-2-78;
Damp heat, cyclic, according to IEC 60068-2-30
Ambient temperature °C 0 - +40, to 60 with a reduction of Ie of 2 % per C
Ambient temperature storage °C -25 - 60 -25 - 60 -25 - 60
Installation altitude m 0 - 1000, to 2000 m with a current consumption of 1% per 100 m
Mounting position Vertical Vertical Vertical
Protection type IP20 IP20 IP20
Protection against direct contact Finger- and back-of-hand proof
Pollution degree 2 2 2
Power loss at rated operational current Ie W 545 662 795
Dimensions (W x H x D) mm 338 x 520 x 248 338 x 520 x 248 338 x 520 x 248
Weight kg 15.7 22 22
Main contacts
Rated operating voltage Ue V AC 230 - 460 230 - 460 230 - 460
Rated insulation voltage Ui V AC 460 460 460
Mains frequency Hz 50/60 50/60 50/60
Control section power supply UC V AC 110/230 110/230 110/230
Rated operational current
Motor load (AC-53) Ie A 202 242 300
Assigned motor rating (standard connection)
230 V P kW 55 75 90
400V P kW 110 132 160
480 V P HP 150 200 250
Phase current
In-delta terminal type A 349 419 519
Assigned motor rating (in-delta terminal type)
230 V kW 110 132 160
400 V kW 160 200 250
480 V HP 250 350 400
Overload cycle to IEC/EN 60947-4-2
AC-53a (without bypass) 202 A: AC-53a: 3-35: 60-10 242 A: AC-53a: 3-35: 60-10 300 A: AC-53a: 3-35: 60-3
Short-circuit rating
Type “1” of coordination NZM7-200N NZM7-250N NZM10-400N/ZM-400
Type “2” of coordination additionally 20.610.32-450 20.610.32-500 20.610.32-500
DM4
