DM4 soft starters
Long start-up time
Bypass contactor
(optional)10)
Circuit-breakers
Controller supply
Semiconductor fuse (optional, in addition to the protective devices for type “1” coordination,
required for type “2” coordination)
Fuses Fuse holders
Number x Part no. Number x Part no.
DILM7 PKZM0-0,16 3 x 20.282.20-80 3 x 21.189.01
DILM17 PKZM0-0,16 3 x 20.282.20-80 3 x 21.189.01
DILM25 PKZM0-0,16 3 x 20.282.20-125 3 x 21.189.01
DILM40 PKZM0-0,16 3 x 20.282.20-125 3 x 21.189.01
DILM65 PKZM0-0,16 3 x 20.189.20-200 3 x 21.189.01
DILM65 PKZM0-0,16 3 x 20.189.20-200 3 x 21.189.01
DILM95 PKZM0-0,16 3 x 20.610.32-350 3 x 21.313.02
DILM115 PKZM0-0,16 3 x 20.610.32-350 3 x 21.313.02
DILM150 PKZM0-0,16 3 x 20.610.32-450 3 x 21.313.02
DILM185 PKZM0-0,16 3 x 20.610.32-450 3 x 21.313.02
DILM185 PKZM0-0,16 3 x 20.610.32-500 3 x 21.313.02
DILM185 PKZM0-0,16 3 x 20.610.32-500 3 x 21.313.02
DILM225 PKZM0-0,16 3 x 20.610.32-630 3 x 21.313.02
DILM400 PKZM0-1.6 3 x 20.630.32-900 3 x 21.313.02
DILM400 PKZM0-1.6 3 x 20.630.32-900 3 x 21.313.02
DILM500 PKZM0-1.6 3 x 20.630.32-1250 3 x 21.313.02
DILM580 PKZM0-1.6 3 x 20.630.32-1250 3 x 21.313.02
DILM7 PKZM0-0,16 3 x 20.282.20-40 3 x 21.189.01
DILM17 PKZM0-0,16 3 x 20.282.20-80 3 x 21.189.01
DILM25 PKZM0-0,16 3 x 20.282.20-125 3 x 21.189.01
DILM40 PKZM0-0,16 3 x 20.282.20-125 3 x 21.189.01
DILM40 PKZM0-0,16 3 x 20.282.20-125 3 x 21.189.01
DILM65 PKZM0-0,16 3 x 20.189.20-200 3 x 21.189.01
DILM65 PKZM0-0,16 3 x 20.189.20-200 3 x 21.189.01
DILM95 PKZM0-0,16 3 x 20.610.32-350 3 x 21.313.02
DILM150 PKZM0-0,16 3 x 20.610.32-350 3 x 21.313.02
DILM150 PKZM0-0,16 3 x 20.610.32-450 3 x 21.313.02
DILM150 PKZM0-0,16 3 x 20.610.32-450 3 x 21.313.02
DILM185 PKZM0-0,16 3 x 20.610.32-450 3 x 21.313.02
DILM185 PKZM0-0,16 3 x 20.610.32-500 3 x 21.313.02
DILM225 PKZM0-0,16 3 x 20.610.32-630 3 x 21.313.02
DILM400 PKZM0-1.6 3 x 20.630.32-900 3 x 21.313.02
DILM400 PKZM0-1.6 3 x 20.630.32-900 3 x 21.313.02
DILM500 PKZM0-1.6 3 x 20.630.32-1250 3 x 21.313.02
DILM580 PKZM0-1.6 3 x 20.630.32-1250 3 x 21.313.02
4)
5)
6)
7)
8)
9)
10)
In the case of motors with the same rating but with a higher current than the one specified, a switch/contactor with greater speci-
fications must be used if necessary. The motor current is decisive in this case.
If the soft starter remains continually live, it can also act as overload relay.
For delta connection, set overload relay to the value motor current/√3.
Overload trip block set to tr = ∞
In delta connection, the overload relay is connected in series with the motor winding (set to value motor current/√3).
To use IZM as “contactor”, accessories are required l (see chapter 5). In that case, the recommended circuits may not apply since
different contacts may have to be assigned depending on the selected accessories.
The bypass is dimensioned according to AC-1. If the bypass has to be opened immediately in the event of an emergency stop, it must
be dimensioned according to AC-3.
In this case, the contactors in the "Mains contactor" column must be used.
