DM4 soft starters
DM4 soft starters
DM4-340-200K DM4-340-250K DM4-340-315K DM4-340-400K DM4-340-500K
IEC/EN 60947-4-2
UL, cUL UL, cUL UL, cUL UL, cUL UL, cUL
Damp heat, constant, according to IEC 60068-2-78;
Damp heat, cyclic, according to IEC 60068-2-30
0 - +40, to 60 with a reduction of Ie of 2 % per C
-25 - 60 -25 - 60 -25 - 60 -25 - 60 -25 - 60
0 - 1000,to 2000 m with a current consumption of 1% per 100 m
Vertical Vertical Vertical Vertical Vertical
IP20 IP20 IP20 IP20 IP20
Finger- and back-of-hand proof
2 2 2 2 2
925 1371 1705 2106 2775
338 x 520 x 248 640 x 610 x 375 640 x 610 x 375 640 x 610 x 375 640 x 610 x 375
22 56 65 72 72
230 - 460 230 - 460 230 - 460 230 - 460 230 - 460
460 460 460 460 460
50/60 50/60 50/60 50/60 50/60
110/230 110/230 110/230 110/230 110/230
370 500 600 750 900
110 132 160 200 250
200 250 315 400 500
300 400 500 600 750
640 866 1039 1299 1558
200 250 315 400 500
315 400 560 750 900
500 600 850 1100 1300
370 A: AC-53a: 3-35: 60-3 500 A: AC-53a: 3-35: 60-3 600 A: AC-53a: 3-35: 60-3 750 A: AC-53a: 3-35: 60-3 900 A: AC-53a: 3-35: 60-3
NZM10-400N/ZM-400 NZM10-630N/ZM-630 NZM10-630N/ZM-630 NZM14-800S NZM14-1000S
20.610.32-630 20.610.32-900 20.610.32-900 20.610.32-1250 20.610.32-1250
9/59
DM4
