Rated operational current 32 A
Can be used universally.
690
–
45
2
PKZM0…, PKE +
DILM…
BBA0-32/2TS-C
2)
116708
4
off
Universal adapter 1-, 2- and 3-
phase applications.
Mounting rail can be moved within
1.25
mm grid.
For conductor cross-sections,
round conductors of up to 6 mm
2
.
Only busbaradapters/wiring sets
manufactured on or after CW 35/
2009
can be used for PKE.
For DOL starters.
690
AWG 10
(6
mm²)
45
2
PKZM0, PKE +
DILM17
PKZM0, PKE +
DILM25
PKZM0, PKE +
DILM32
MSC-D-16-M17… -
MSC-D-32-M32…
BBA0-32
1)
101452
4
off
In combination with individual
components PKZM0 and DILM
wiring kit PKZM0-XM32DE can be
used.
Fully assembled and tested
combination with MSC-D
￫Page 8/2
Only busbar adapters/wiring sets
manufactured on or after CW35/
2009
can be used for PKE.
For soft starters
690
AWG 10
(6
mm²)
45
2
PKZM0, PKE +
DS7...016N...
PKZM0, PKE +
DS7...024N...
PKZM0, PKE +
DS7...032N...
BBA0L-32
142527
1
off
–
For 160 mm adapter system with motor-protective circuit-breakers
–
690
AWG 10
(6
mm²)
45
1
PKZM0, PKE
BBA0K-32
142528
1
off
–
Rated operational current 63 A
For DOL starters.
690
AWG 8
(10
mm²)
55
2
PKZM4 + DILM17
PKZM4 + DILM25
PKZM4 + DILM32
PKZM4 + DILM40
PKZM4 + DILM50
PKZM4 + DILM65
BBA4L-63
1)
101459
4
off
The following can be used to
establish an electrical connection:
For PKZM4 + DILM17 to DILM32:
MVS-LB0-0M-G
For PKZM4 + DILM40 to DILM65:
PKZM4-XM65DE.
690
AWG 8
(10
mm²)
72
2
PKZ2 + DILM7
PKZ2 + DILM9
PKZ2 + DILM12
PKZ2 + DILM15
PKZ2 + DILM17
PKZ2 + DILM25
PKZ2 + DILM32
PKZ2 + DILM40
BBA2L-63
1)
101480
4
off
The following can be used to
establish an electrical connection:
For PKZ2 + DILM7 to DILM12:
MVS-LB0-00M-G
For PKZ2 + DILM15 to DILM32:
MVS-LB0-0M-G.
For motor-protective circuit-breakers
690
AWG 8
(10
mm²)
54
1
PKZM4
BBA4-63
1)
101457
4
off
–
690
AWG 8
(10
mm²)
72
1
PKZ2
BBA2-63
1)
101458
4
off
–
Information relevant for export to North America
1)
2)
Product Standards UL 508A; CSA-C22.2 No. 14; IEC60439-1; CE marking
UL File No.
E300273
UL CCN
NMTR, NMTR7
CSA File No.
232140
CSA Class No.
3211-37
NA Certification
UL Listed, CSA certified
Max. Voltage Rating 600 V AC
Product Standards UL 508A; CSA-C22.2 No. 14; IEC60439-1; CE marking
UL File No.
E300273
UL CCN
NMTR, NMTR7
NA Certification
UL Listed, CSA certified
Max. Voltage Rating 600 V AC
Rated
operational
voltage
Conductor
cross-
section
Adapter
width
Mounting
rails
For use with
Part no.
Article no.
Price
See
price list
Std. pack
Notes
U
e
V
mm Number
