Motor-protective circuit-breakers PKZM01, PKZM0, PKZM4, PKE
Accessories
2010 CA08103002Z-EN
7/21
Accessories
Notes Part no.
Article no.
Price
See price
list
Std. pack Information relevant for export to
North America
Telescopic adapters
With 45 mm top-hat rail to IEC/EN 60715 for compensation of the
mounting depth of rear-mounted devices enclosures CI-K and cabinets
Telescopic clip Stepless
adjustment via
scale from
75 – 115 mm.
M22-TA
226161
1 off Product Standards IEC/EN 60947-5;
UL 508; CSA-C22.2
No. 14-05; CSA-
C22.2 No. 94-91;
CE marking
UL File No. E29184
UL CCN NKCR
CSA File No. 012528
CSA Class No. 3211-03
NA Certification UL Listed,
CSA certified
Lockable rotary handle
For locking motor-protective
circuit-breakers PKZM0, PKZM4
and PKE as a main switch in
compliance with EN 60204.
Can be padlocked in the “0”
position.
Hasp thickness: 3 – 6.35 mm
Can not be
combined with
VHI-PKZ0.
AK-PKZ0
030851
5 off Product Standards UL 508; CSA-C22.2
No.14;IEC60947-4-1;
CE marking
UL File No. E36332
UL CCN NLRV
CSA File No. 12528
CSA Class No. 3211-05
NA Certification UL Listed,
CSA certified
Holding facility
To prevent tampering with the
overload release and the test
function, it can be sealed using
industry standard sealing wire
For use with motor-protective
circuit-breakers PKZM0 and
PKZM4
– PL-PKZ0
203599
5 off
Mounting angle bracket
For screw fixing to mounting
plate
– PKE32-XMB
134837
20 off Product Standards UL 508; CSA-C22.2
No.14;IEC60947-4-1;
CE marking
NA Certification Request filed for UL
and CSA
Documentation
Motor-protective circuit-
breakers PKZM0, overload
monitoring of EEx e motors
German/English AWB1210-1458D/GB
266164
1 off
Motor-protective circuit-
breakers PKZM4, overload
monitoring of EEx e motors
German/English AWB1210-1457D/GB
266165
Motor-protective circuit-
breakers PKE, EEx electric
motor overload monitoring
German/English AWB1210-1631DE/EN
134836
For use with Color Voltage Part no.
Article no.
Price
See price
list
Std. pack
Us
V
Indicator lights with glow lamp
CI-K2-PKZ0-… , CI-K4-PKZ4 ,
CI-PKZ0(1) , E-PKZ0(1)
White 110 - 230 L-PKZ0(230V)
082151
10 off
CI-K2-PKZ0-… , CI-K4-PKZ4 ,
CI-PKZ0(1) , E-PKZ0(1)
White 230 - 400 L-PKZ0(400V)
082152
10 off
CI-K2-PKZ0-… , CI-K4-PKZ4 ,
CI-PKZ0(1) , E-PKZ0(1)
White 415 - 500 L-PKZ0(500V)
082153
5 off
CI-K2-PKZ0-… , CI-K4-PKZ4 ,
CI-PKZ0(1) , E-PKZ0(1)
Green 110 - 230 L-PKZ0-GN(230V)
082154
10 off
CI-K2-PKZ0-… , CI-K4-PKZ4 ,
CI-PKZ0(1) , E-PKZ0(1)
Green 230 - 400 L-PKZ0-GN(400V)
082155
10 off
CI-K2-PKZ0-… , CI-K4-PKZ4 ,
CI-PKZ0(1) , E-PKZ0(1)
Green 415 - 500 L-PKZ0-GN(500V)
082156
5 off
CI-K2-PKZ0-… , CI-K4-PKZ4 ,
CI-PKZ0(1) , E-PKZ0(1)
Red 110 - 230 L-PKZ0-RT(230V)
082157
10 off
CI-K2-PKZ0-… , CI-K4-PKZ4 ,
CI-PKZ0(1) , E-PKZ0(1)
Red 230 - 400 L-PKZ0-RT(400V)
082158
10 off
