Motor-protective circuit-breakers PKZM01, PKZM0, PKZM4, PKE
Incoming terminals
2010
CA08103002Z-EN
www.eaton.com7/27
Incoming terminals
Circuit-
breakers
For use
with
Unit width
Part no.
Article no.
Price
See price
list
Std. pack
Notes
Number
mm
Shroud for unused terminals
Protection against direct contact.
For covering unused terminals on three-phase commoning link B3...-PKZ0
–
–
–
H-B3-PKZ0
1)
032721
20
off
–
Incoming terminals
–
PKZM0
PKE
–
BK25/3-PKZ0
2)
032720
5
off
For three-phase commoning link,
protected against accidental contact,
U
e
= 690 V, I
u
= 63 A
For conductor cross-sections:
2.5 - 25
mm
2
stranded
2.5 - 16
mm
2
flexible with ferrule
AWG 14 - 6, usable on terminals 1, 3,
and 5
–
PKZM0
–
BK25/3-PKZ0-E
3)
262518
5
off
For three-phase commoning link,
protected against accidental contact,
U
e
= 690 V, I
u
= 60 A
For conductor cross-sections:
2.5 - 25
mm
2
stranded
2.5 - 16
mm
2
flexible with ferrule
AWG 14 - 6
For assembly of Type E starters.
–
PKZM4
–
BK50/3-PKZ4-E
4)
272165
1
off
Can be combined with three-phase
commoning link B3…PKZ4.
I
u
= 120 A.
For assembly of Type E starters.
Information relevant for export to North America
1)
2)
Product Standards
UL 508; CSA-C22.2 No. 14; IEC60947-4-1;
CE marking
UL File No.
E36332
UL CCN
NLRV
CSA File No.
98494
CSA Class No.
3211-06
NA Certification
UL Listed, CSA certified
Product Standards
UL 508; CSA-C22.2 No. 14; IEC60947-4-1;
CE marking
UL File No.
E36332
UL CCN
NLRV
CSA File No.
12528
CSA Class No.
3211-05
NA Certification
UL Listed, CSA certified
3)
4)
Product Standards
UL 508; CSA-C22.2 No. 14; IEC60947-4-1;
CE marking
UL File No.
E36332
UL CCN
NLRV
CSA File No.
98494
CSA Class No.
3211-06
NA Certification
UL Listed, CSA certified
Specially designed for NA ✓
Suitable for
PKZM0/PKE, line terminal required for
Type E/F applications
Product Standards
UL 508; CSA-C22.2 No. 14; IEC60947-4-1;
CE marking
UL File No.
E36332
UL CCN
NLRV
CSA File No.
12528
CSA Class No.
3211-06
NA Certification
UL Listed, CSA certified
Specially designed for NA ✓
Suitable for
PKZM4/PKE, line terminal required for
Type E/F applications
