2/72 SmartWire-Darwin
SWD RMQ connections
2010 CA08103002Z-EN
www.eaton.comSWDRMQconnections
Technical data
M22-SWD-K11
M22-SWD-KC11
M22-SWD-LED-…
General
Standards
IEC/EN 61131-2
EN 50178
Dimensions (W x H x D)
mm
12 X 42 X 39
12 X 45 X 37
10 X 42 X 45
Weight
g
10
10
10
Mounting position
Any
Ambient mechanical conditions
Protection type (IEC/EN 60529)
IP20
IP20
IP20
Vibrations (IEC/EN 61131-2:2008)
Constant amplitude 3.5 mm
Hz
5 … 8.4
5 … 8.4
5 … 8.4
Constant acceleration, 1 g
Hz
8.4 … 150
8.4 … 150
8.4 … 150
Mechanical shock resistance (IEC/EN 60068-2-27)
Shocks
9
9
9
Drop to IEC/EN 60068-2-31
Drop height
mm
50
50
50
Free fall, packaged (IEC/EN 60068-2-32)
m
0.3
0.3
0.3
Electromagnetic compatibility (EMC)
Overvoltage category
Not applicable
Pollution degree
2
2
2
Electrostatic discharge (IEC/EN 61131-2:2008)
Air discharge (Level 3)
kV
8
8
8
Contact discharge (Level 2)
kV
4
4
4
Electromagnetic fields (IEC/EN 61131-2:2008)
80-1000 MHz
V/m
10
10
10
1.4 - 2 GHz
V/m
3
3
3
2 - 2.7 GHz
V/m
1
1
1
Radio interference suppression (SmartWire-Darwin)
EN 55011 Class A
Burst (IEC/EN 61131-2:2008, Level 3)
Supply cables
kV
2
2
2
SmartWire-Darwin cables
kV
1
1
1
Radiated RFI (IEC/EN 61131-2:2008, Level 3)
V
10
10
10
Ambient climatic conditions
Operating ambient temperature (IEC 60068-2)
°C
–30 … +55
–30 … +55
–30 … +55
Condensation
Prevent with suitable measures
Storage
°C
–40…80
–40…80
–40…80
Relative humidity, non-condensing (IEC/EN 60068-2-30)
%
9 … 95
9 … 95
9 … 95
SmartWire-Darwin network
Station type
SmartWire-Darwin station (slave)
Baud rate setting
Automatic
SmartWire-Darwin status LED
Green
Connections
Plug, 8-pole
Plug connectors
SWD4-8SF2-5
M22-SWD-I…LP SWD4-8SF2-5
Number of mating cycles
50
50
50
Function element
Contacts
1 change-over contact
1 change-over contact
–
Lifespan mechanical/electrical
Operations
1 X 10
6
1 X 10
6
–
LED display
No
No
Yes
Diagnostics
Yes
Yes
No
Fixing
Front fixing
Base fixing
Front fixing
Notes
Maximum current consumption of SWD stations ￫chapter SmartWire-Darwin, page 19
