Eaton Industrial Switchgear - xCommand Control & Indication

2/78 FAK foot and palm switches

2010 CA08103002Z-EN

www.eaton.com

Equipping with contacts:

 = Positive opening safety

function according to

IEC/EN 60947-5-1

Circuit

symbol

Color of

mushroom

head

Indicator

lights

Degree of

protection

N/O=normally

open contact

NC = normally

closed contact

FAK foot and palm switches

Momentary

Enclosure base: black (RAL 9005)

Enclosure top: only light gray (RAL 7035)

1 N/O

1 NC

Black

IP67, IP69K

1 N/O

1 NC

Red

IP67, IP69K

Maintained

Pull to release

Emergency stop pushbutton tamper-proof to

ISO 13850/EN 418

Enclosure base: black (RAL 9005)

Enclosure top: yellow (RAL 1004)

–

1 NC

Red

IP67, IP69K

1 N/O

1 NC

Red

IP67, IP69K

–

2 NC

–

Red

IP67, IP69K

Enclosure base: gray

Enclosure top: yellow

Button, red

Release by button on the side

For Emergency-Stop applications according to ISO 13850

Can also be used as emergency switching off device

1 N/O

1 NC

Red

IP65

Customized complete unit

* = Freely selectable customer identification or stock no.: max. 10 characters

An order consists of: enclosure base, enclosure top, contact elements for base fixing (￫Page 2/31)

￫Engineering

Enclosure base

For max. 3 contact elements

IP67, IP69K

Black

IP67, IP69K

Enclosure top

Momentary

–

Gray

Black

IP67, IP69K

–

Gray

Red

IP67, IP69K

–

Gray

Yellow

IP67, IP69K

Maintained

–

Yellow

Red

IP67, IP69K

ATEX

￫Engineering

Only in conjunction with FAK-COMBINATION-*

For use in accordance with the ATEX directive in dust-laden areas, Zone 22, Category 3

Ordering examples ￫Engineering

IP67, IP69K

ATEX

FAK-...
