RMQ16 pilot devices
RMQ16
2/83
Emergency stop pushbuttons 1
Can also be used as emergency
switching-off devices
Tamper-proof according to
ISO 13850/EN 418
Illuminated and non-illuminated
Additional labels, with and without
inscription
European Machinery Safety
Directive 2006/42/EC
￫Page 2/90
Label mounts 2
For insert labels
Color: light gray, black, yellow
Insert labels, with inscription and
blank
￫Page 2/94
Key-operated buttons 3
2 and 3 positions
Switching angle 45°
Momentary and maintained
Various lock mechanisms
￫Page 2/88
Contact element NC (red) 4
With blade terminal
Universal contacts suitable for use
with electronic devices
Positive opening safety function
according to IEC/EN 60947-5-1
￫Page 2/84
Illuminated pushbutton actuators 5
Momentary and maintained
Replaceable insert labels
Colors: white, green, red, yellow,
blue Custom laser labeling
￫Page 2/85
Contact element N/O (green) 6
With blade terminal
Universal contacts suitable for use
with electronic devices
￫Page 2/84
Selector switch actuators 7
2 and 3 positions
Switching angle 45°
Momentary and maintained
Illuminated selector switch
actuators with built-in lamp socket
Colors: white, green, red
￫Page 2/86
Indicator lights 8
Flat and conical designs
Built-in lamp socket
For filament bulbs and LEDs
Colors: white, green, red, yellow,
blue Custom laser labeling
￫Page 2/89
Pushbutton actuators 9
Momentary and maintained
Replaceable button plates
Colors: white, green, red, yellow,
blue, black
￫Page 2/84
Button plates/insert labels 10
Wear-resistant button plates for
pushbutton actuators
Transparent insert plates for
illuminated pushbuttons and
indicator lights
With and without inscription
With standard texts and symbols or
with custom laser labeling
￫Page 2/91
Labeling with convenience 11
All button plates, indicator lights and
additional button labels from the
RMQ-Titan range can be laser
inscribed with any inscription and
symbol as required.
Download:
,
Keyword: “Labeleditor”
Product Features
• Front dimension and minimum grid
dimensions
18 x 18 mm or 25 x 25 mm
• Mounting diameter 16.2 mm to EN 50007
• Protection type IP65
• For switching differing potentials
• Suitable for use with electronic devices to
IEC/EN 61131-2
• Technical data to IEC/EN 60947-5-1
• Approved throughout the world
