2/88 RMQ16 pilot devices

Key-operated button actuators

2010 CA08103002Z-EN

Key-operatedbuttonactuators

Front dimensions

18 × 18 mm

Front dimensions

25 x 25 mm

Function:

Key withdrawable in

position

Color

Part no.

Article no.

Part no.

Article no.

Price

See

price

list

Std. pack

Information relevant for export to

North America

=Momentary

=Maintained

IP65, key-operated button actuators

With 1 key and VS anti-rotation feature

Two positions

45°

–

0

–

Q18S1

038806

Q25S1

038773

5 off

Product Standards IEC/EN 60947-5;

UL 508; CSA-

C22.2 No. 14-05;

CE marking

UL File No.

E29184

UL CCN

NKCR

CSA File No.

46552

CSA Class No.

3211-03

NA Certification

UL Listed,

CSA certified

Degree of Protection UL/CSAPartno.1

45°

I

0

–

Q18S1R

038805

Q25S1R

038772

45°

–

0

–

Q18S1R-A1

072312

Q25S1R-A1

072376

45°

–

0

–

Q18S1-GN

062148

Q25S1-GN

062150

45°

I

0

–

Q18S1R-GN

062151

Q25S1R-GN

062108

45°

–

0

–

Q18S1-RT

046841

Q25S1-RT

046843

45°

I

0

–

Q18S1R-RT

046837

Q25S1R-RT

046839

45°

–

0

–

Q18S1-WS

046849

Q25S1-WS

046851

45°

I

0

–

Q18S1R-WS

046845

Q25S1R-WS

046847

45°

–

0

–

Q18S1-BL

045959

Q25S1-BL

046835

45°

I

0

–

Q18S1R-BL

062814

Q25S1R-BL

045502

Three positions

45°45°

–

0

–

Q18S3

072313

Q25S3

072377

5 off

45°45°

I

0

II

Q18S3R

072314

Q25S3R

072378

45°45°

–

0

–

Q18S3R-A1

072315

Q25S3R-A1

072379

45°45°

I

0

–

Q18S3R-A2

072316

Q25S3R-A2

072380

45°45°

–

0

II

Q18S3R-A3

072317

Q25S3R-A3

072381

45°45°

I

0

–

Q18S3R-A4

072318

Q25S3R-A4

072382

45°45°

–

0

–

Q18S3R-A5

072319

Q25S3R-A5

072383

45°45°

–

0

II

Q18S3R-A6

072320

Q25S3R-A6

072384

45°45°

–

0

–

Q18S3R-A7

072321

Q25S3R-A7

072385

45°45°

–

0

–

Q18S3-GN

062149

Q25S3-GN

062153

45°45°

I

0

II

Q18S3R-GN

062152

Q25S3R-GN

062147

45°45°

–

0

–

Q18S3-RT

046842

Q25S3-RT

046844

45°45°

I

0

II

Q18S3R-RT

046838

Q25S3R-RT

046840

45°45°

–

0

–

Q18S3-WS

046850

Q25S3-WS

046852

45°45°

I

0

II

Q18S3R-WS

046846

Q25S3R-WS

046848

45°45°

–

0

–

Q18S3-BL

046368

Q25S3-BL

046836

45°45°

I

0

II

Q18S3R-BL

064430

Q25S3R-BL

045646

Notes

For each color there is a corresponding key.

￫Page 2/97

Accessories

Page

Assembly aids and

accessories

￫2/96

Contact elements

N/O

￫2/84

NC

￫2/84

Q18S..., Q25S...

HPL02088EN
