RMQ16 pilot devices
Marking plates
2010 CA08103002Z-EN
2/91
Markingplates
Button plates for pushbutton actuators
18 x 18 mm 25 × 25 mm
Inscription Symbol Part no.
Article no.
Part no.
Article no.
Price
See price
list
Std. pack Information relevant for export to
North America
Marking plates
– 01TQ18
086816
01TQ25
091121
20 off UL/CSA certification not required
– 02TQ18
086859
02TQ25
091149
– 03TQ18
087766
03TQ25
091184
– 04TQ18
087834
04TQ25
091442
– 05TQ18
087867
05TQ25
091471
– 06TQ18
087920
06TQ25
091506
With customized inscription via
Labeleditor ￫Notes
XQ18D-*-*1)
285286
XQ25D-*-*1)
285287
1 off
OFF 10TQ18
087951
10TQ25
091536
20 off
STOP or OFF 19TQ18
054510
19TQ25
054508
ON 11TQ18
088007
11TQ25
091562
START or ON 20TQ18
054509
20TQ25
054507
START or ON 21TQ18
088061
21TQ25
091586
Direction of movement 32TQ18
088125
32TQ25
091618
Direction of movement 36TQ18
088275
36TQ25
092592
Electr. voltage 34TQ18
095386
34TQ25
092563
Increase 37TQ18
088315
37TQ25
092608
Decrease 38TQ18
088340
38TQ25
092645
Manual actuation 40TQ18
088389
40TQ25
092709
Automatic 41TQ18
088412
41TQ25
092774
ON–OFF, momentary 43TQ18
088426
43TQ25
092791
Unlock 52TQ18
088452
52TQ25
092825
Lock 53TQ18
088487
53TQ25
092874
Loosen 54TQ18
088512
54TQ25
093013
Clamp 55TQ18
088545
55TQ25
093032
Liquid START 921TQ25
047426
Liquid STOP 63TQ18
088566
63TQ25
093060
Horn 66TQ18
088590
66TQ25
093092
Spindle START 811TQ25
053898
Spindle STOP 814TQ25
047425
ON–OFF, maintained 899TQ18
089232
899TQ25
093063
Notes 1) When ordering, complete part no. XQ18D-*-* or XQ25D-*-*:
1st wildcard * ≙ Color, e.g.: -R, -G, -B, -W, -Y, -S
2nd wildcard * ≙ File name generated by Labeleditor ￫Engineering
Illuminated pushbutton actuator, Indicator light, laser inscription ￫Page 2/97
...TQ18, ...TQ25, ...LQ18, ...LQ25 HPL02091EN
