2/74 SmartWire-Darwin
SWD accessories
2010 CA08103002Z-EN
www.eaton.comSWDaccessories
SWD4-RC8-10
SWD4-8SF2-5
SWD4-8SFF2-5
General
Standards
IEC/EN 61131-2
EN 50178
Dimensions (W x H x D)
mm
48.5 x 34.5 x 10
15 x 36.5 x 17.5
48.5 x 34.5 x 10
Weight
g
10
5.5
4.5
Mounting position
Any
Any
Any
Ambient mechanical conditions
Protection type (IEC/EN 60529)
IP20
IP20
IP20
Vibrations (IEC/EN 61131-2:2008)
Constant amplitude 3.5 mm
Hz
5 … 8.4
5 … 8.4
5 … 8.4
Constant acceleration, 1 g
Hz
8.4 … 150
8.4 … 150
8.4 … 150
Mechanical shock resistance (IEC/EN 60068-2-27)
semi-sinusoidal 15 g/11 ms
Shocks
9
9
9
Drop to IEC/EN 60068-2-31
Drop height
mm
50
–
–
Free fall, packaged (IEC/EN 60068-2-32)
m
0.3
–
–
Electromagnetic compatibility (EMC)
Overvoltage category
II
–
–
Pollution degree
2
–
–
Electrostatic discharge (IEC/EN 61131-2:2008)
Air discharge (Level 3)
kV
8
–
8
Contact discharge (Level 2)
kV
4
–
4
Electromagnetic fields (IEC/EN 61131-2:2008)
80-1000 MHz
V/m
10
–
–
1.4 - 2 GHz
V/m
3
–
–
2 - 2.7 GHz
V/m
1
–
–
Radio interference suppression (SmartWire-Darwin)
EN 55011 Class A
–
–
Burst (IEC/EN 61131-2:2008, Level 3)
SmartWire-Darwin cables
kV
1
–
–
Radiated RFI (IEC/EN 61131-2:2008, Level 3)
V
10
–
–
Ambient climatic conditions
Operating ambient temperature
(IEC 60068-2)
°C
–25 … +55
–25 … +55
–25 … +55
Condensation
Prevent with suitable measures
Storage
°C
–40…70
–40…70
–40…70
Relative humidity, non-condensing
(IEC/EN 60068-2-30)
%
5 … 95
5 … 95
5 … 95
Connection options
SWD-In
Plug, 8-pole
Plug connector
Plug, 8-pole
Number of mating cycles
≥200
1
³ 200
SWD-Out
–
Socket, 8-pole
Plug, 8-pole
Number of mating cycles
–
≥200
≥200
Notes
Maximum current consumption of SWD stations ￫chapter SmartWire-Darwin, page 19
SWD4...
