Eaton Industrial Switchgear - xCommand Control & Indication

73 / 336

2/70 SmartWire-Darwin
Accessories
2010 CA08103002Z-EN
Accessories
Mounting locations Part no.
Article no.
Price
See price
list
Std. pack Information relevant for export to
North America
Number
Printed circuit boards
PCBs for surface mounting enclosure M22-I.. for mounting base function
elements M22-SWD...K
Integrated, connectable SWD network terminator.
Number of mounting locations : 1 M22-SWD-I1-LP01
115990
1 off NA Certification Request filed for
UL and CSA
Number of mounting locations : 2 M22-SWD-I2-LP01
115991
Number of mounting locations : 3 M22-SWD-I3-LP01
115992
Number of mounting locations : 4 M22-SWD-I4-LP01
115993
Number of mounting locations : 6 M22-SWD-I6-LP01
115994
Bridge
Bridging of open mounting locations of device plug or M22-SWD-I PCB
Link for unused mounting locations of
M22-SWD-I...LP (base fixing)
M22-SWD-SEL8-10
116698
5 off NA Certification Request filed for
UL and CSA
Connectors for SWD round cables
8-pole socket, straight SWD4-SF8-67
116033
1 off NA Certification Request filed for
UL and CSA
8-pole plug, straight SWD4-SM8-67
116034
8-pole socket, 90° angled SWD4-SF8-67W
116035
8-pole plug, 90° angled SWD4-SM8-67W
116036
Housing bushing socket
For flushmounting in surface mounting enclosure M22-I...
8-pole socket/ plug, IP67, for connection to SWD4-S(M,F)-67...
8 prefabricated cables for connection to PCB M22-SWD-I...
8-pole socket, M20 SWD4-SF8-20
116031
1 off NA Certification Request filed for
UL and CSA
8-pole plug, M20 SWD4-SM8-20
116032
1 off
IN
OUT
OFF
ON
M22-SWD..., SWD4-... HPL02070EN
