SmartWire-Darwin
SWD RMQ connections
2/67
4-way selector switch actuators 1
￫Page 2/20
Labels with label mounts 2
￫Page 2/25
4-way adapter 3
￫Page 1/11
Fixing adapters 4
￫Page 1/11
Function element with 3 positions
for front fixing 5
￫Page 1/10
LED element for front fixing 6
￫Page 1/11
M22 contact elements 7
￫Page 2/31
Function element with 2 positions
and LED for front fixing
8
￫Page 1/10
Function element with 3 positions
and LED for front fixing 9
￫Page 1/10
Link for external device plug 10
￫Page 1/17
Front fixing contacts 11
￫Page 2/31
SWD external device plug 12
￫Page 1/17
SWD ribbon flat cable 13
￫Page 1/17
Planning and ordering help,
SWD?Assist 14
￫ Features
M22 surface mounting enclosure 15
￫Page 2/45
PCB for built-in surface mounting
enclosure
16
￫Page 1/11
Enclosure bushing for round cable 17
￫Page 2/46
Enclosure bushing plug/socket 18
￫Page 1/18
Plug connectors for SWD round
cables 19
￫Page 1/18
SWD round cable 20
￫Page 1/18
Contacts for base fixing 21
￫Page 2/31
Link for base slots 22
￫Page 1/11
Function element with 3 positions
and LED for base fixing
23
￫Page 1/10
Function element with 3 positions
for base fixing 24
￫Page 1/10
Function element with 2 positions
and LED for base fixing
25
￫Page 1/10
Function element with 2 positions
for base fixing 26
￫Page 1/10
LED element for base fixing 27
￫Page 1/11
Bezels 28
￫Page 2/48
Double pushbutton actuators 29
￫Page 2/16
Labels for label mounts 30
￫Page 2/35
Indicator lights 32
￫Page 2/26
Key-operated buttons 33
￫Page 2/21
Selector switch actuators 34
￫Page 2/20
Pushbutton actuators 36
￫Page 2/17
Button plates/Button lenses 35
￫Page 2/36
Label mounts 31, 37
￫Page 2/35
Emergency switching off
pushbutton
38
￫Page 2/7
Joystick 39
￫Page 2/24
4-way pushbutton 40
￫Page 2/24
Features
• SWD-RMQ connection for front fixing
￫Page 1/10
– Adaption with standard adapter M22-A or
M22-SWD-A4 for 4-way pushbutton
– Combination with standard pilot devices
of the M22 series.
– Types with one or two change-over
contacts and with/without integrated
LED element
– SmartWire-Darwin diagnostics LED for
signalling the communication status of
the function element
– Connection to SmartWire-Darwin flat
band cable via external device plug.
• Link for external device plug￫Page 1/11
– Connection to SmartWire-Darwin
external device plug.
– Suitable for the bridging of already
adapted SmartWire-Darwin external
device plugs (e.g. as a placeholder)
• Planning and ordering help (SWD‐Assist)
– Free download at:
.
– Easy generation of applications with the
system SmartWire-Darwin.
– Integrated function for the generation of
ordering lists.
– Integrated validity check.
• Surface mounting enclosure with PCB
￫Page 1/11
– Connection of SmartWire-Darwin
RMQ elements for base fixing.
– Type with 1, 2, 3, 4 and 6 slots
– Bridging of free slots with links for base
fixing.
– Integrated switchable terminating
resistor.
• Housing bushing socket￫Page 1/18
– Use for M22 surface mounting enclosure
or control panel.
– Type plug/socket.
– Prefabricated signal cable with ferrules
for connection to PCB for surface
mounting enclosure.
• SWD-RMQ connection for base fixing
￫Page 1/10
– Use with surface mounting enclosure for
M22 control circuit devices.
– Combination with standard pilot devices
of the M22 series.
– Types with one or two change-over
contacts and with/without integrated
LED element
– SmartWire-Darwin diagnostics LED for
signalling of the communication status of
the function element.
– Connection to SmartWire-Darwin via PCB
for built-in enclosure.
