Eaton Industrial Switchgear - xCommand Control & Indication

71 / 336

2/68 SmartWire-Darwin
SWD RMQ connections
2010 CA08103002Z-EN
SWDRMQconnections
Num-
ber of
con-
tacts
Circuit
symbol
Contact travel
diagram, stroke in
connection with
front element
Configuration Colour LED Part no.
Article no.
Price
See
price
list
Std. pack Information relevant for
export to North America
Function elements
Front fixing
1 without
LED
– M22-SWD-K11
115964
20 off NA Certification Request
filed for
UL and
CSA
2 without
LED
– M22-SWD-K22
115965
10 off
Base fixing
1 without
LED
– M22-SWD-KC11
115995
20 off
2 without
LED
– M22-SWD-KC22
115996
10 off
Front fixing
1 – M22-SWD-K11LED-W
115972
20 off
1 – M22-SWD-K11LED-B
115973
1 – M22-SWD-K11LED-G
115974
1 – M22-SWD-K11LED-R
115975
2 – M22-SWD-K22LED-W
115978
10 off
2 – M22-SWD-K22LED-B
115979
2 – M22-SWD-K22LED-G
115980
2 – M22-SWD-K22LED-R
115981
Base fixing
1 – M22-SWD-K11LEDC-W
116003
20 off
1 – M22-SWD-K11LEDC-B
116004
1 – M22-SWD-K11LEDC-G
116005
1 – M22-SWD-K11LEDC-R
116006
2 – M22-SWD-K22LEDC-W
116009
10 off
2 – M22-SWD-K22LEDC-B
116010
2 – M22-SWD-K22LEDC-G
116011
2 – M22-SWD-K22LEDC-R
116012
0 1.2 2.8 5.5
1
4
3
6
2
5
0 1.2 2.8 5.5
1
4
3
6
2
5
0 1.2 2.8 5.5
3 1 2
0 1.2 2.8 5.5
3 1 2
0 1.2 2.8 5.5
1
4
3
6
2
5
0 1.2 2.8 5.5
1
4
3
6
2
5
0 1.2 2.8 5.5
3 1 2
0 1.2 2.8 5.5
3 1 2
M22-SWD... HPL02068EN
