FAK foot and palm switches

2/77

System overview

7

8

5

6

1

2

3

4

Enclosure base

7

Prepared for contact elements

Base fixing (not for ...SMC... contacts)

￫Page 2/78

Operator only with mushroom

head

1, 2, 3, 4

Various color combinations

Yellow/red for Emergency stop

or emergency switching off

applications

European Machinery Safety

Directive 2006/42/EC

For foot or hand operation

￫Page 2/78

Contact elements

5

Base fixing

￫Page 2/31

Indicator lights

6, 8

Conical

BA9s base

￫Page 2/26
