RMQ-Titan control circuit devices
Surface mounting enclosures
2010 CA08103002Z-EN
www.eaton.com2/45
Surfacemountingenclosures
Surfacemountingenclosures
Mounting
locations
Cable entry knockouts
Color
RAL value
Protection
type
Part no.
Article no.
Price
See price
list
Std. pack
Floor
Pages
Number
Number ×M… Number ×M…
Surface mounting enclosures
With high-grade steel screws
Enclosure base: anthracite
ATEX part numbers for use in dust-laden areas, Zone 22, Category 3
￫Engineering
For emer-
gency-switch-
ing-off
pushbuttons
1
2 x 16
1 x 20
2 x 25/20
RAL 1004
IP67, IP69K
M22-IY1
216536
1 off
1
2 x 16
1 x 20
2 x 25/20
RAL 1004
IP67, IP69K
M22-IY1-ATEX
104370
1 off
1
2 x 16
1 x 20
2 x 25/20
RAL 7035
IP67, IP69K
M22-I1
216535
1 off
1
2 x 16
1 x 20
2 x 25/20
RAL 7035
IP67, IP69K
M22-I1-ATEX
104371
1 off
2
2 x 20
1 x 20
2 x 25/20
RAL 7035
IP67, IP69K
M22-I2
216537
1 off
2
2 x 20
1 x 20
2 x 25/20
RAL 7035
IP67, IP69K
M22-I2-ATEX
104372
1 off
3
2 x 20
2 x 20
2 x 25/20
RAL 7035
IP67, IP69K
M22-I3
216538
1 off
3
2 x 20
2 x 20
2 x 25/20
RAL 7035
IP67, IP69K
M22-I3-ATEX
104373
1 off
4
2 x 20
2 x 20
2 x 25/20
RAL 7035
IP67, IP69K
M22-I4
216539
1 off
4
2 x 20
2 x 20
2 x 25/20
RAL 7035
IP67, IP69K
M22-I4-ATEX
104374
1 off
6
2 x 20
2 x 20
2 x 25/20
RAL 7035
IP66
M22-I6
216540
1 off
6
2 x 20
2 x 20
2 x 25/20
RAL 7035
IP66
M22-I6-ATEX
104375
1 off
Notes
Information relevant for export to North America
Product Standards IEC/EN 60947-5; UL 508; CSA-C22.2 No. 14-05; CSA-C22.2 No. 94-91; CE marking
UL File No.
E29184
UL CCN
NKCR
CSA File No.
012528
CSA Class No.
3211-03
NA Certification
UL Listed, CSA certified
Degree of Protection UL/CSA Type 3R, 4X, 12, 13
ATEX
M22
HPL02045EN
