RMQ-Titan control circuit devices
Lenses for illuminated pushbuttons
2010 CA08103002Z-EN
2/43
Lenses for illuminatedpushbuttons
Style flat Style extended
Inscription
or explanation
For use with Color,
symbol
Part no.
Article no.
Price
See price
list
Std. pack Part no.
Article no.
Price
See price
list
Std. pack Informationrelevant
for export to
North America
Lenses for illuminated pushbutton actuators
≦ 5 characters: letter height 5 mm
> 5 characters: letter height 3 mm
RESET M22(S)-DL-X
M22(S)-DRL-X
M22S-DGL-X
M22-XDL-B-GB14
218336
10 off M22-XDLH-B-GB14
218379
10 off UL/CSA certification
not required
FORWARD M22-XDL-W-GB15
218337
M22-XDLH-W-GB15
218380
REVERSE M22-XDL-W-GB16
218338
M22-XDLH-W-GB16
218381
RAISE M22-XDL-W-GB17
218339
M22-XDLH-W-GB17
218382
LOWER M22-XDL-W-GB18
218340
M22-XDLH-W-GB18
218383
Stopp M22-XDL-R-X0
218159
M22-XDLH-R-X0
218161
Stopp M22-XDL-W-X0
218160
M22-XDLH-W-X0
218162
Start M22-XDL-G-X1
218295
M22-XDLH-G-X1
218341
Start M22-XDL-W-X1
218296
M22-XDLH-W-X1
218342
Start M22-XDL-G-X2
218297
M22-XDLH-G-X2
218343
Start M22-XDL-W-X2
218301
M22-XDLH-W-X2
218344
Increase M22-XDL-W-X4
218302
M22-XDLH-W-X4
218345
Acceptance M22-XDL-W-X5
218303
M22-XDLH-W-X5
218346
Reset M22-XDL-B-X6
218304
M22-XDLH-B-X6
218347
Directions M22-XDL-W-X7
218305
M22-XDLH-W-X7
218348
Directions M22-XDL-W-X8
218306
M22-XDLH-W-X8
218349
Hand M22-XDL-W-X9
218307
M22-XDLH-W-X9
218350
Automatic M22-XDL-W-X10
218308
M22-XDLH-W-X10
218351
Inch M22-XDL-W-X11
218309
M22-XDLH-W-X11
218352
Unlock M22-XDL-W-X12
218310
M22-XDLH-W-X12
218353
Loosen M22-XDL-W-X13
218311
M22-XDLH-W-X13
218354
Clamp M22-XDL-W-X14
218312
M22-XDLH-W-X14
218355
Release M22-XDL-W-X15
218313
M22-XDLH-W-X15
218356
Liquid M22-XDL-W-X16
218314
M22-XDLH-W-X16
218357
Horn M22-XDL-W-X17
218315
M22-XDLH-W-X17
218358
M22-XDL(H)... HPL02043EN
