2/44 RMQ-Titan control circuit devices
Flush Mounting Panels, Shrouds
2010 CA08103002Z-EN
FlushMountingPanels,Shrouds
Protec-
tion
type
Mounting
locations
Color RAL
value
Knock-
out cable
entries
Part no.
Article
no.
Price
See
price
list
Std. pack Information relevant for
export to North America
Number Number
× M20
Flush mounting panels
No legend plates possible with vertical arrangements
Protection type only in conjunction with a suitable enclosure and correct mounting.
Aluminium
with yellow
paint finish for
Emergency
switching off
IP65 1 RAL 1004 – M22-EY1
216542
5 off Product Standards IEC/EN 60947-5;
UL 508; CSA-C22.2
No.14-05;CSA-C22.2
No. 94-91;
CE marking
UL File No. E29184
UL CCN NKCR
CSA File No. 012528
CSA Class No. 3211-03
NA Certification UL Listed,
CSA certified
Degree of Protection UL/CSA Type 3R, 4X,
12, 13
Aluminium
light anodized,
including
M22-XE...
1 RAL 7035 – M22-E1
216541
2 – M22-E2
216543
3 – M22-E3
216544
4 – M22-E4
216545
1 off
5 – M22-E5
216546
IP40 6 – M22-E6
216547
Shrouds
Plastic, light grey
Protection type only in combination with flush mounting plates
M22-E…
IP55 1 RAL 7035 3 M22-H1
216548
1 off Product Standards IEC/EN 60947-5;
UL 508;
CSA-C22.2No.14-05;
CSA-C22.2No.94-91;
CE marking
UL File No. E29184
UL CCN NKCR
CSA File No. 012528
CSA Class No. 3211-03
NA Certification UL Listed,
CSA certified
Degree of Protection UL/CSA Type 3R, 4X,
12, 13
2 4 M22-H2
216549
3 4 M22-H3
216550
IP40 4 4 M22-H4
216551
5 5 M22-H5
216552
6 6 M22-H6
216553
Set of plaster keys
Comprising two plaster keys as mounting aids
For plastering of shrouds
- – – – – M22-UPE
216554
1 off Product Standards IEC/EN 60947-5;
UL 508; CSA-C22.2
No.14-05;CSA-C22.2
No. 94-91;
CE marking
UL File No. E29184
UL CCN NKCR
CSA File No. 012528
CSA Class No. 3211-03
NA Certification UL Listed,
CSA certified
Degree of Protection UL/CSA Type 3R, 4X,
12, 13
M22-E..., M22-H... HPL02044EN
