2/40 RMQ-Titan control circuit devices
Lenses for indicator lights
2010 CA08103002Z-EN
www.eaton.comLenses for indicator lights
Style flat
Style extended
Inscription
or explanation
For use with
Color
Part no.
Article no.
Price
See
price
list
Std. pack
Part no.
Article no.
Price
See
price
list
Std. pack
Information rele-
vant for export to
North America
Lenses for indicator lights
≦ 5 characters: letter height 5 mm
> 5 characters: letter height 3 mm
–
M22-L-X
M22-LC-X
M22-XL-W
216453
10 off
M22-XLH-W
216459
10 off
UL/CSA certifica-
tion not required
–
M22-XL-R
216454
M22-XLH-R
216460
–
M22-XL-G
216455
M22-XLH-G
216461
–
M22-XL-Y
216456
M22-XLH-Y
216462
–
M22-XL-B
216457
M22-XLH-B
216463
With customized
inscription via
Labeleditor
￫Note
–
M22-XL-*-*
1)
216458
Zu
M22-XL-W-D2
218403
Auf
M22-XL-W-D3
218404
Ab
M22-XL-W-D4
218405
Aus
M22-XL-R-D5
218406
Ein
M22-XL-W-D6
218407
Vorwärts
M22-XL-W-D15
218408
Rückwärts
M22-XL-W-D16
218409
Heben
M22-XL-W-D17
218410
Senken
M22-XL-W-D18
218411
STOP
M22-XL-R-GB0
218412
STOP
M22-XL-W-GB0
218413
START
M22-XL-G-GB1
218414
START
M22-XL-W-GB1
218415
CLOSE
M22-XL-W-GB2
218416
UP
M22-XL-W-GB3
218417
DOWN
M22-XL-W-GB4
218418
TEST
M22-XL-W-GB9
218419
OFF
M22-XL-R-GB5
218420
ON
M22-XL-W-GB6
218421
FORWARD
M22-XL-W-GB15
218422
Notes
1)
When ordering, the part no must include the following details:
1st wildcard ≙ color: ‐R, ‐G, ‐B, ‐W, ‐Y, ‐S
2nd wildcard ≙ file name generated by Labeleditor ￫Engineering
1)
Text size 3 mm:
Text size 5 mm:
max. 8 characters in first line,
10 characters in second line,
8 characters in third line
Max. 5 characters per line
ABCD E FGH
ABCD E FGH
ABCD E FGHM Z
A B C D E
M22-XL...
HPL02040EN
