2/38 RMQ-Titan control circuit devices
Button plates for pushbutton actuators
2010 CA08103002Z-EN
Buttonplates forpushbuttonactuators
Inscription
or explanation
For use with Color Part no.
Article no.
Price
See price
list
Std. pack Information relevant for export to
North America
Button plates for mushroom-headed pushbuttons
≦ 5 characters: letter height 5 mm
> 5 characters: letter height 3 mm
– M22(S)-D(R)P-... M22-XDP-S
216435
10 off UL/CSA certification not required
– M22-XDP-W
216436
– M22-XDP-R
216437
– M22-XDP-G
216438
– M22-XDP-Y
216439
with customized inscription via
Labeleditor ￫Note
– M22-XDP-*-*1)
216440
Zu M22-XDP-S-D2
218272
Auf M22-XDP-S-D3
218273
Ab M22-XDP-S-D4
218274
Aus M22-XDP-R-D5
218275
Ein M22-XDP-S-D6
218276
Vorwärts M22-XDP-S-D15
218277
Rückwärts M22-XDP-S-D16
218278
Heben M22-XDP-S-D17
218279
Senken M22-XDP-S-D18
218280
STOP M22-XDP-R-GB0
218281
STOP M22-XDP-S-GB0
218282
START M22-XDP-G-GB1
218283
START M22-XDP-W-GB1
218284
CLOSE M22-XDP-S-GB2
218285
UP M22-XDP-S-GB3
218286
DOWN M22-XDP-S-GB4
218287
OFF M22-XDP-R-GB5
218289
ON M22-XDP-S-GB6
218290
TEST M22-XDP-S-GB9
218288
FORWARD M22-XDP-S-GB15
218291
REVERSE M22-XDP-S-GB16
218292
Notes 1) When ordering, the part no must include the following details:
1st wildcard * ≙ color: ‐R, ‐G, ‐B, ‐W, ‐Y, ‐S, -GR
2nd wildcard * ≙ file name generated by Labeleditor ￫Engineering
1)
1)
Text size 3 mm: Text size 5 mm:
max. 8 characters in first line,
10 characters in second line,
8 characters in third line
Max. 5 characters per line
ABCD E FGH
ABCD E FGH
ABCD E FGHM Z A B C D E
M22-XDP... HPL02038EN
