2/34 RMQ-Titan pilot devices
LED elements
2010 CA08103002Z-EN
www.eaton.comLEDelements
LED elements with Cage Clamp
￫Engineering
Cage Clamp is a registered trademark of
Wago Kontakttechnik GmbH/Minden, Germany
Front
mounting
12-30 V AC/DC 8 - 15
0.26 at 24 V
M22-CLED-W
216569
20 off
Product Standards IEC/EN 60947-5;
UL 508;
CSA-C22.2No.14-05;
CSA-C22.2No.94-91;
CE marking
UL File No.
E29184
UL CCN
NKCR
CSA File No.
012528
CSA Class No.
3211-03
NA Certification
UL Listed,
CSA certified
Degree of Protection UL/CSA Type: -
M22-CLED-R
216570
M22-CLED-G
216571
M22-CLED-B
218061
85 - 264 V AC,
50/60 Hz
5 - 15
0.33 at 230 V
M22-CLED230-W
216575
20 off
M22-CLED230-R
216576
M22-CLED230-G
216577
M22-CLED230-B
218063
Base fixing 12-30 V AC/DC 8 - 15
0.26 at 24 V
M22-CLEDC-W
216572
20 off
M22-CLEDC-R
216573
M22-CLEDC-G
216574
M22-CLEDC-B
218062
85 - 264 V AC,
50/60 Hz
5 - 15
0.33 at 230 V
M22-CLEDC230-W
216578
20 off
M22-CLEDC230-R
216579
M22-CLEDC230-G
216580
M22-CLEDC230-B
218064
LED series elements with screw terminals
Front and base fixing￫Engineering
LED resistor element
For connecting 12-30 V LED elements
42-60 V AC/DC
M22-XLED60
231078
10 off
Product Standards IEC/EN 60947-5;
UL 508;
CSA-C22.2 No. 14-05;
CSA-C22.2 No. 94-91;
CE marking
UL File No.
E29184
UL CCN
NKCR
CSA File No.
012528
CSA Class No.
3211-03
NA Certification
UL Listed,
CSA certified
Degree of Protection UL/CSA Type: -
220 V AC/DC
M22-XLED220
1)
271541
LED test element
For de-coupled function test (lamp test)
12-240 V AC/DC
M22-XLED-T
231079
85 - 264 V AC
M22-XLED230-T
231080
Notes
For pushbutton actuators, indicator lights, illuminated pushbutton actuators and illuminated selector switch actu-
ators, the following applies:
M22...-R only in combination with M22-LED...-R
M22...-G only in combination with M22-LED...-G
M22...-W only in combination with M22-LED...-W
M22...-Y only in combination with M22-LED...-W
M22...-B in combination with M22-LED…-W or M22-LED…-B
1)
Maximum ambient temperature: -25 °C to +55 °C
The LED brightness is reduced.
Rated
operational
voltage
Rated
operational
current
Power
consumption
Color
Part no.
Article no.
Price
See price
list
Std. pack
Information relevant for export to
North America
U
e
I
e
P
V
mA
W
M22-CLED
