32 / 336
RMQ-Titan pilot devices
Illuminated pushbutton actuators
2010 CA08103002Z-EN
www.eaton.com2/29
￫Engineering
Bezel gold-plated￫Page 2/48
Extended Maintained
M22-DRLH-W
216788
5 off
M22S-DRLH-W
216791
5 off
Programmable
maintained/momentary
pushbutton function
M22-DRLH-R
216789
M22S-DRLH-R
216792
M22-DRLH-G
216796
M22S-DRLH-G
216798
M22-DRLH-Y
216799
M22S-DRLH-Y
216801
M22-DRLH-B
216802
M22S-DRLH-B
216803
M22-DRLH-R-X0
216804
M22S-DRLH-R-X0
216808
M22-DRLH-G-X1
216805
M22S-DRLH-G-X1
216809
M22-DRLH-W-X0
216806
M22S-DRLH-W-X0
216810
M22-DRLH-W-X1
216807
M22S-DRLH-W-X1
216811
Bezel gold-plated￫Page 2/48
with guardring
Momentary
–
M22-DGL-X
230961
5 off
Information relevant for export to North America
Product Standards IEC/EN 60947-5; UL 508; CSA-C22.2 No. 14-05; CSA-C22.2 No. 94-91; CE marking
UL File No.
E29184
UL CCN
NKCR
CSA File No.
012528
CSA Class No.
3211-03
NA Certification
UL Listed, CSA certified
Degree of Protection UL/CSA Type 3R, 4X, 12, 13
Bezel: Silver
Bezel: black
Color
Part no.
Article no.
Price
See price
list
Std. pack
Part no.
Article no.
Price
See price
list
Std. pack
Notes
Button
plate
ATEX
≈ 3 mm
M22-DR...
O I
O I
M22-D...
M22(S)-R..., M22(S)-DL...
HPL02029EN
