2/24 RMQ-Titan pilot devices
Four-way operators, 4 positions
2010 CA08103002Z-EN
Four-way operators, 4positions
Bezel: Silver Bezel: black
Inscrip-
tion
Function: For use
with
Part no.
Article no.
Price
See
price list
Std. pack Part no.
Article no.
Price
See
price list
Std. pack
=Momentary
=Maintained
Joystick, IP66
￫Engineering
Bezel gold-plated￫Page 2/48, use adapter M22-A4
￫Page 1/11With one operating point per operating direction
2 positions – M22-WJ2H
289195
1 off M22S-WJ2H
289197
1 off
– M22-WRJ2H
289199
M22S-WRJ2H
289241
– M22-WJ2V
289196
M22S-WJ2V
289198
– M22-WRJ2V
289240
M22S-WRJ2V
289242
4 positions – M22-WRJ4
279415
5 off M22S-WRJ4
279416
5 off
4 positions – M22-WJ4
279417
5 off M22S-WJ4
279418
5 off
Information relevant for export to North America Product Standards IEC/EN 60947-5; UL 508; CSA-C22.2 No. 14-05; CSA-C22.2 No. 94-91;
CE marking
UL File No. E29184
UL CCN NKCR
CSA File No. 012528
CSA Class No. 3211-03
NA Certification UL Listed, CSA certified
Degree of Protection UL/CSA Type 3R, 4X, 12, 13
With two operating points per operating direction
These joysticks are combined with normal normally open contacts
M22-K10 and normally open contacts M22-K10P.
2 positions – M22-WJ2H-2P
111508
1 off
2 positions – M22-WJ2V-2P
111507
1 off
4 positions – M22-WJ4-2P
110836
1 off
Information relevant for export to North America NA Certification Request filed for UL and CSA
Pushbuttons, IP66, 4-way
￫ Engineering
Pushbuttons not
mechanically
interlocked
No inscription, push-
button color black
– M22-D4-S
279411
5 off M22S-D4-S
279412
5 off
Custom pushbutton
color and inscription,
￫Notes
– M22-D4-*-*
279413
5 off M22S-D4-*-*
279414
5 off
Arrows white, push-
button color black
– M22-D4-S-X7
286336
5 off M22S-D4-S-X7
286337
5 off
Opposite pushbutton
mechanically inter-
locked
Arrows white, push-
button color black
– M22-DI4-S-X7
286338
5 off M22S-DI4-S-X7
286339
5 off
Custom pushbutton
color and inscription,
￫Notes
– M22-DI4-*-*
286340
5 off M22S-DI4-*-*
286341
5 off
Notes Information relevant for export to North America
-*-*: * B = blue, G = green, R = red, B = black, W = white, Y = yellow
State colors clockwise, starting at 12:00 o'clock
-*-*: * = File name generated by Labeleditor
￫Engineering
Product Standards IEC/EN 60947-5; UL 508; CSA-C22.2 No. 14-05; CSA-C22.2 No. 94-91;
CE marking
UL File No. E29184
UL CCN NKCR
CSA File No. 012528
CSA Class No. 3211-03
NA Certification UL Listed, CSA certified
Degree of Protection UL/CSA Type 3R, 4X, 12, 13
ATEX
ATEX
B
S
G
W
