2/20 RMQ-Titan pilot devices
Selector switch actuators
2010 CA08103002Z-EN
Selector switchactuators
Bezel: Silver Bezel: black
Function:
=Momentary
Button
plate
Inscription Function Part no.
Article no.
Price
See
price
list
Std. pack Part no.
Article no.
Price
See
price
list
Std. pack
=Maintained
Selector switch actuators, IP66
￫Engineering; Bezel gold-plated￫Page 2/48
Maintained/momentary, can be changed with coding adapter kit ￫Page 2/23
Two positions
With rotary knob
40° – – M22-W
216853
5 off M22S-W
216854
5 off
60° – – M22-WR
216855
M22S-WR
216856
60° – – M22-WR-X92
216857
M22S-WR-X92
216858
60° AUTO HAND – M22-WR-X91
216859
M22S-WR-X91
216860
60° * = with customized
inscription through
Labeleditor￫Engineering
– M22-WR-*
226836
M22S-WR-*
226837
With thumb-grip
40° – – – M22-WK
216865
5 off M22S-WK
216866
5 off
60° – – – M22-WRK
216867
10 off M22S-WRK
216869
10 off
60° – – – M22-WRK-GVP
216868
50 off off
With thumb-grip, V position
60° – – – M22-WKV
216874
5 off M22S-WKV
216875
5 off
3 positions (with plunger bridge￫engineering)
With rotary knob
40°40° – – M22-W3
216861
5 off M22S-W3
216862
5 off
60°60° – – M22-WR3
216863
M22S-WR3
216864
60°60° AUTO 0 MAN. – M22-WR3-X94
226838
M22S-WR3-X94
226839
60°60° * = with customized
inscription through
Labeleditor￫Engineering
– M22-WR3-*
226840
M22S-WR3-*
226841
With thumb-grip
40°40° – – – M22-WK3
216870
5 off M22S-WK3
216871
5 off
60°60° – – – M22-WRK3
216872
M22S-WRK3
216873
– – – M22-WRK3-*1)
217436
M22S-WRK3-*1)
217437
4 positions
Not suitable for coding adapters
Use fixing adapter M22-A4 ￫Page 2/31,labels￫Page 2/25
With rotary knob
45° – M22-WR4
279419
5 off M22S-WR4
279430
5 off
With thumb-grip
45° – M22-WRK4
279431
5 off M22S-WRK4
279432
5 off
Notes
1) The * wildcard can represent
values 1 or 2:
* = 1: for 60° 40°
* = 2: for 40° 60°
Information relevant for export to North America
Product Standards IEC/EN 60947-5; UL 508; CSA-C22.2 No. 14-05; CSA-C22.2 No. 94-91; CE marking
UL File No. E29184
UL CCN NKCR
CSA File No. 012528
CSA Class No. 3211-03
NA Certification UL Listed, CSA certified
Degree of Protection UL/CSA Type 3R, 4X, 12, 13
ATEX
0 1
0
2
03
0
4
0 1
0
2
03
0
4
M22-W(R)K... HPL02020EN
