2/16 RMQ-Titan pilot devices
Double puhbutton actuators
2010 CA08103002Z-EN
Doublepuhbuttonactuators
Bezel: silver Bezel: black
Construction
type
Button plate Part no.
Article no.
Price
Seeprice
list
Part no.
Article no.
Price
Seeprice
list
Std. pack Information relevant for export
to North America
Double pushbutton actuators
with indicator light, IP66
￫Engineering
White acillary lens
Momentary
Bezel gold-plated￫Page 2/48
Pushbuttons
and indica-
tor lights
protruding
M22-DDL-GR
216698
M22S-DDL-GR
216699
5 off Product Standards IEC/EN 60947-5;
UL 508;
CSA-C22.2 No. 14-05;
CSA-C22.2 No. 94-91;
CE marking
UL File No. E29184
UL CCN NKCR
CSA File No. 012528
CSA Class No. 3211-03
NA Certification UL Listed, CSA
certified
Degree of Protection UL/CSA Type 3R,
4X, 12, 13
M22-DDL-GR-X1/X0
216700
M22S-DDL-GR-X1/X0
216701
M22-DDL-GR-GB1/
GB0
216702
M22S-DDL-GR-GB1/
GB0
216703
M22-DDL-WS
216704
M22S-DDL-WS
216705
M22-DDL-WS-X1/X0
216706
M22S-DDL-WS-X1/X0
216707
M22-DDL-WS-GB1/
GB0
216708
M22S-DDL-WS-GB1/
GB0
216709
M22-DDL-S-X7/X7
216710
M22S-DDL-S-X7/X7
216711
M22-DDL-S-X4/X5
218145
M22S-DDL-S-X4/X5
218146
With customized
inscription to
order via
Labeleditor
￫Notes
M22-DDL-*-*-*
226770
M22S-DDL-*-*-*
230350
Pushbuttons
andindicator
lights flat
M22-DDLF-GR-X1/X0
284814
M22S-DDLF-GR-X1/X0
284815
5 off Product Standards IEC/EN 60947-5;
UL 508;
CSA-C22.2 No. 14-05;
CSA-C22.2 No. 94-91;
CE marking
NA Certification Request filed for UL
and CSA
Degree of Protection UL/CSA Type 3R, 4X,
12, 13
M22-DDLF-WS-X1/X0
284816
M22S-DDLF-WS-X1/X0
284817
With customized
inscription to
order via
Labeleditor
￫Notes
M22-DDLF-*-*-*
284818
M22S-DDLF-*-*-*
284819
Pushbutton I
andindicator
light flat,
pushbutton0
protruding
M22-DDLM-GR-X1/X0
284830
M22S-DDLM-GR-X1/X0
284831
5 off
M22-DDLM-WS-X1/
X0
284832
M22S-DDLM-WS-X1/
X0
284833
With customized
inscription to
order via
Labeleditor
￫Notes
M22-DDLM-*-*-*
107062
