2/18 RMQ-Titan pilot devices
Pushbuttons
2010 CA08103002Z-EN
Pushbuttons
Bezel: silver Bezel: black
Button plate Part no.
Article no.
Price
See price
list
Std. pack Part no.
Article no.
Price
See price
list
Std. pack Notes
Pushbutton actuators IP67, IP69K
￫Engineering
Bezel gold-plated￫Page 2/48
Actuator extended,
momentary
M22-DH-S
216636
5 off M22S-DH-S
216637
5 off –
M22-DH-W
216638
M22S-DH-W
216639
–
M22-DH-G
216643
M22S-DH-G
216645
–
M22-DH-R
216641
M22S-DH-R
216642
–
M22-DH-Y
216646
M22S-DH-Y
216647
–
M22-DH-B
216649
M22S-DH-B
216650
–
M22-DH-R-X0
216655
M22S-DH-R-X0
216656
–
M22-DH-G-X1
216657
M22S-DH-G-X1
216658
–
M22-DH-S-X0
216659
M22S-DH-S-X0
216660
–
M22-DH-W-X1
216661
M22S-DH-W-X1
216662
–
Actuator extended,
maintained
M22-DRH-S
216663
5 off M22S-DRH-S
216664
5 off Programmable
maintained/momentary
pushbutton function
M22-DRH-W
216665
M22S-DRH-W
216666
M22-DRH-R
216667
M22S-DRH-R
216668
M22-DRH-G
216669
M22S-DRH-G
216670
M22-DRH-Y
216671
M22S-DRH-Y
216672
M22-DRH-B
216673
M22S-DRH-B
216674
M22-DRH-R-X0
216675
M22S-DRH-R-X0
216676
M22-DRH-G-X1
216677
M22S-DRH-G-X1
216678
M22-DRH-S-X0
216679
M22S-DRH-S-X0
216680
M22-DRH-W-X1
216681
M22S-DRH-W-X1
216682
Pushbuttons with guard ring,
momentary, IP66, IP69K
￫Engineering
Bezel gold-plated￫Page 2/48
– M22-DG-X
220921
5 off –
Information relevant for export to North America Product Standards IEC/EN 60947-5; UL 508; CSA-C22.2 No. 14-05; CSA-C22.2 No. 94-91; CE marking
UL File No. E29184
UL CCN NKCR
CSA File No. 012528
CSA Class No. 3211-03
NA Certification UL Listed, CSA certified
Degree of Protection UL/CSA Type 3R, 4X, 12, 13
ATEX
≈ 3 mm
M22-DR...
O I O I
M22-D...
ATEX
M22-D(R)H... HPL02018EN
