RMQ-Titan pilot devices
Mushroom-headed pushbutton
2010 CA08103002Z-EN
2/19
Mushroom-headedpushbutton
Bezel: silver Bezel: black
Button
plate
Colour of
mushroom
head
Part no.
Article no.
Price
See price
list
Std. pack Part no.
Article no.
Price
See price
list
Std. pack Notes
Mushroom-headed pushbuttons,
IP67, IP69K
￫Engineering
Bezel gold-plated￫Page 2/48
Momentary M22-DP-S
216712
5 off M22S-DP-S
216713
5 off –
M22-DP-R
216714
M22S-DP-R
216715
–
M22-DP-G
216716
M22S-DP-G
216717
–
M22-DP-Y
216718
M22S-DP-Y
216719
–
M22-DP-R-X0
216720
M22S-DP-R-X0
216721
–
M22-DP-G-X1
216722
M22S-DP-G-X1
216723
–
M22-DP-S-X0
216724
M22S-DP-S-X0
216725
–
M22-DP-W-X1
216726
M22S-DP-W-X1
216727
–
– M22-DP-S-X
216728
M22S-DP-S-X
216730
–
– M22-DP-R-X
216731
M22S-DP-R-X
216733
–
– M22-DP-G-X
216734
M22S-DP-G-X
216736
–
– M22-DP-Y-X
216737
M22S-DP-Y-X
216739
–
Maintained M22-DRP-S
216743
5 off M22S-DRP-S
216744
5 off Programmable
maintained/
momentary
pushbutton function
M22-DRP-R
216745
M22S-DRP-R
216746
M22-DRP-G
216747
M22S-DRP-G
216748
M22-DRP-Y
216749
M22S-DRP-Y
216750
M22-DRP-R-X0
216751
M22S-DRP-R-X0
216752
M22-DRP-G-X1
216753
M22S-DRP-G-X1
216754
M22-DRP-S-X0
216755
M22S-DRP-S-X0
216756
M22-DRP-W-X1
216757
M22S-DRP-W-X1
216758
– M22-DRP-S-X
216759
M22S-DRP-S-X
216761
– M22-DRP-R-X
216762
M22S-DRP-R-X
216764
– M22-DRP-G-X
216765
M22S-DRP-G-X
216767
– M22-DRP-Y-X
216768
M22S-DRP-Y-X
216770
Information relevant for export to North America Product Standards IEC/EN 60947-5; UL 508; CSA-C22.2 No. 14-05; CSA-C22.2 No. 94-91; CE marking
UL File No. E29184
UL CCN NKCR
CSA File No. 012528
CSA Class No. 3211-03
NA Certification UL Listed, CSA certified
Degree of Protection UL/CSA Type 3R, 4X, 12, 13
ATEX
≈ 3 mm
M22-DR...
O I O I
M22-D...
