RMQ-Titan pilot devices
Complete units for surface mounting
2010 CA08103002Z-EN
www.eaton.com2/15
Completeunits forsurfacemounting
Bezel: silver
Number
of loca-
tions
Contact configuration:
= Safety function by
positive opening according
to IEC/EN 60947‐5‐1
Circuit symbol
Color enclosure
top
Protec-
tion
type
Part no.
Article no.
Price
See
price list
Std. pack
Number N/O = normally
open contact
NC=normally
closed
contact
RAL no.
Pushbutton actuator
Flush actuator
1
1 N/O
1 NC
RAL
7035
IP67,
IP69K
M22-D-G-X1/KC11/I
216522
1 off
1
1 N/O
1 NC
RAL
7035
IP67,
IP69K
M22-D-R-X0/KC11/I
216521
1 off
Information relevant for export to North America
Product Standards IEC/EN 60947-5; UL 508; CSA-C22.2 No. 14-05; CSA-C22.2 No. 94-91; CE marking
UL CCN
NKCR
CSA File No.
012528
CSA Class No.
3211-03
NA Certification
UL Listed, CSA certified
Degree of Protection UL/CSA Type 3R, 4X, 12, 13
Key-operated button
Maintained/momentary function and key withdraw convertible with coding adapters M22-XC￫Engineering
with 1 key
2 positions, maintained
Lock mechanism MS1
1
1 N/O
1 NC
RAL
7035
IP66
M22-WRS/KC11/I
216526
1 off
Two-way pushbutton station
Without indicator light
Without indicator light
2
2 N/O
2 NC
RAL
7035
IP67,
IP69K
M22-I2-M1
216529
1 off
With indicator light,
white
LED element
85 - 264 V AC
2
2 N/O
2 NC
RAL
7035
IP67,
IP69K
M22-I3-M2
216533
1 off
Three-way pushbutton station
3
3 N/O
3 NC
RAL
7035
IP67,
IP69K
M22-I3-M1
216532
1 off
ustomized complete unit
￫Engineering
To order use form FO315 ￫ Data sheet in Online Catalog
* = Freely selectable customer identification or stock no.; max. 10 characters.
M22-COMBINATION-*
228298
1 off
Information relevant for export to North America
Product Standards IEC/EN 60947-5; UL 508; CSA-C22.2 No. 14-05; CSA-C22.2 No. 94-91; CE marking
UL File No.
E29184
UL CCN
NKCR
CSA File No.
012528
CSA Class No.
3211-03
NA Certification
UL Listed, CSA certified
Degree of Protection UL/CSA Type 3R, 4X, 12, 13
14
13
22
21
14
13
22
21
14
13
22
21
22
21
14
13
22
21
14
13
22
21
14
13
22
21
14
13
22
21
14
13
22
21
14
13
22
21
14
13
