2/10 RMQ-Titan pilot devices
Accessories
2010 CA08103002Z-EN
www.eaton.comAccessories
RAL value
Protection
type
Part no.
Article no.
Price
See price
list
Std. pack
Information relevant for export
to North America
Guard-ring
Protection against accidental actuation
RAL 1004
IP65
M22-XGPV
231273
1 off
Product Standards IEC/EN 60947-5;
UL 508; CSA-C22.2
No. 14-05;CSA-C22.2
No. 94-91;
CE marking
UL File No.
E29184
UL CCN
NKCR
CSA File No.
012528
CSA Class No.
3211-03
NA Certification
UL Listed, CSA
certified
Degree of Protection UL/CSA Type 3R, 4X,
12, 13
Sealable shroud
For devices with mushroom diameter 38 mm
transparent with collapse point, can be reused after Emergency Stop/
switching off in a 30 × 50 grid, adjacent drilling dimensions must be
closed with blanking plugs M22(S)-B
–
IP65
M22-PL-PV
216397
2 off
UL/CSA certification not required
LED-Illuminated ring
Yellow with yellow LEDs
￫Engineering (circuit diagrams)
60 mm diameter
24 V AC/DC
Three groups of 4 LEDs each (in series), can be actuated separately
(e.g. for run light)
M22-XPV60-Y-24
121477
1 off
NA Certification
Request filed for UL
and CSA
60 mm diameter
120 V AC
One group of 8 LEDs (in series)
M22-XPV60-Y-120
121476
1 off
60 mm diameter
230 V AC
One group of 8 LEDs (in series)
M22-XPV60-Y-230
138280
1 off
Customized complete unit
￫Engineering
To order use form F0315
￫Data sheet in Online Catalog
* = Freely selectable customer identification or stock no.;
max. 10 characters.
M22-COMBINATION-*
228298
1 off
Note:
Contact elements￫Page 2/32
M22-X...
