RMQ-Titan pilot devices
RMQ-Titan
2/5
Emergency stop pushbuttons
Emergency switching off
pushbuttons
Mushroom-shaped
1
Non-illuminated
Illuminated with LED
with Lock mechanism MS1–MS20
with lock mechanism for master key
system
Tamper-proof according to
ISO 13850/EN 418
European Machinery Safety
Directive 2006/42/EC
Can be secured by sealable shroud
Additional labels, with and without
inscription
Release by turning
￫Page 2/7
Emergency stop pushbuttons
Emergency switching off label
Palm-tree shape
2
Non-illuminated
Diameter 45 mm and 60 mm
Tamper-proof according to
ISO 13850/EN 418
European Machinery Safety
Directive 2006/42/EC
Additional labels, with and without
inscription
Release by turning
￫Page 2/8
Emergency stop pushbuttons
Emergency switching off
pushbuttons
Palm-tree shape
3
Illuminated with LED
Diameter 45 mm and 60 mm
Tamper-proof according to
ISO 13850/EN 418
European Machinery Safety
Directive 2006/42/EC
Additional labels, with and without
inscription
Release by turning
￫Page 2/8
Emergency stop pushbuttons
Emergency switching off
pushbuttons
Palm-tree shape
4
with mechanical operated indicator
Diameter 45 mm and 60 mm
Tamper-proof according to
ISO 13850/EN 418
European Machinery Safety
Directive 2006/42/EC
Additional labels, with and without
inscription
Release by turning
￫Page 2/9
Emergency stop pushbuttons
Emergency switching off
pushbuttons
Palm-tree shape
5
with lock mechanism MS1–MS20
Diameter 45 mm and 60 mm
Tamper-proof according to
ISO 13850/EN 418
European Machinery Safety
Directive 2006/42/EC
Additional labels, with and without
inscription
Release by turning
￫Page 2/8
Emergency stop pushbuttons
Emergency switching off
pushbuttons
Palm-tree shape
6
with Ronis 455 lock mechanism
Diameter 45 mm and 60 mm
Tamper-proof according to
ISO 13850/EN 418
European Machinery Safety
Directive 2006/42/EC
Can be secured by sealable shroud
Additional labels, with and without
inscription
Release by turning or pulling
￫Page 2/9
Emergency stop labels
Emergency switching off label 7
Round, square, and rectangular
types
Single-language, multi-language,
can be individually labeled
￫Page 2/11
Illuminated ring 8
Versions: 24 V AC/DC, 120 V AC,
230 V AC
Continuous light
Flashing light with separate
actuation
Continuous light with separate
actuation, 24 V AC/DC
can be actuated separately with
three LED rows
￫Page 2/10
Guardring 9
against accidental actuation
for 38 mm and 45 mm designs
￫Page 2/10
Mounting adapter 10
For flush mounting plates
for contact and LED elements,
M22-A...
for contact elements, M22-A4
￫Page 2/31
Contact elements, indicator lights 11
Normally open contact and normally
closed contact
Universalcontacts suitable for use
with electronic devices
Positive opening safety function
according to IEC/EN 60947-5-1
Up to 2 levels with 3 contact
elements each
￫Page 2/31
Surface mounting enclosure 12
Surface mounting enclosures IP67
up to 6 mounting locations
Surface mounting enclosures IP55
up to 12 mounting locations
Flush mounting plate, IP54, up to
6 mounting locations
Shrouds IP40 for flush mounting
￫Page 2/45
Labeling with convenience 13
All button plates, indicator lights and
additional button labels from the
RMQ-Titan range can be laser
inscribed with any inscription and
symbol as required.
Download:
Keyword: “Labeleditor”
Accessories 14
￫Page 2/48
