2/6 RMQ-Titan pilot devices
Complete units for flush mounting
2010 CA08103002Z-EN
www.eaton.comComplete units for flush mounting
Completeunits forsurfacemounting
Bezel: Silver
Contact configuration:
= Safety function by
positive opening according
to IEC/EN 60947‐5‐1
Circuit
symbol
Protec-
tion
type
Part no.
Article no.
Price
See price list
Std. pack
Notes
N/O= normally
open contact
NC = normally
closedcontact
Emergency switching-off actuators
Tamper-proof according to ISO 13850/EN 418
Pull to release
Max. contacts to be fitted together: 4 x M22-(C)K…
Red mushroom head (RAL 3000), yellow base
–
1 NC
IP66,
IP69K
M22-PV/K01
216515
5 off
1 N/O
1 NC
IP66,
IP69K
M22-PV/K11
216516
5 off
Emergency switching-off key-release mushroom
Tamper-proof according to ISO 13850/EN 418
with one key, individual lock mechanismMS1, not suitable for master key systems
Release by using the key
Red mushroom head (RAL 3000), yellow base
–
1 NC
IP66,
IP69K
M22-PVS/K01
216514
5 off
Bezel: silver
Number
of loca-
tions
Contact configuration:
= Safety function by
positive opening accord-
ing to IEC/EN 60947‐5‐1
Circuit
symbol
Enclosure
top
RAL value Protec-
tion
type
Part no.
Article no.
Price
See price
list
Std. pack
Number N/O = nor-
mally open
NC = nor-
mally closed
Emergency switching-off actuators
Tamper-proof according to
ISO 13850/EN 418
Pull to release
–
–
2 NC
RAL 1004 IP66,
IP69K
M22-PV/KC02/IY
216524
1 off
–
1 N/O
1 NC
RAL 1004 IP66,
IP69K
M22-PV/KC11/IY
216525
1 off
Emergency switching-off key-release mushroom
with 1 key
Lock mechanism MS1
1
1 N/O
RAL 1004 IP67,
IP69K
M22-PVS/KC11/IY
216523
1 off
customized complete unit
To order use form F0315 ￫Data sheet in Online Catalog
* = Freely selectable customer identification or stock no.; max. 10 characters.
M22-COMBINATION-*
228298
1 off
Notes
Information relevant for export to North America
Product Standards
IEC/EN 60947-5; UL 508; CSA-C22.2 No. 14-05; CSA-C22.2 No. 94-91; CE marking
UL File No.
E29184
UL CCN
NKCR
CSA File No.
012528
CSA Class No.
3211-03
NA Certification
UL Listed, CSA certified
Degree of Protection
UL/CSA Type 3R, 4X, 12, 13
21
22
21
22
13
14
21
22
12
11
22
21
14
13
22
21
14
13
22
21
M22-...
