www.eaton.comRMQ-Titan pilot devices
RMQ-Titan
2/3
4-way selector switch actuators
1
4 positions
With rotary head or thumb-grip
Maintained function 0-1-0-2-0-3-0-4
￫Page 2/20
Labels with label mounts
2
Colour: aluminium-coloured
Labels: inscribed,
can be inscribed individually, blank
￫Page 2/25
Fixing adapters
3
For flush mounting plates
for contact and LED elements,
M22-A...
for contact elements, M22-A4
￫Page 2/31
(Double) contact elements
4
Normally closed contact (NC) and
normally open contact (N/O)
Universalcontacts suitable for use
with electronic devices
Positive opening safety function
according to IEC/EN 60947-5-1
Maximum 2 levels, each with
3 contact elements
￫Page 2/31
LED elements
4
Voltage range:
12 – 30 V AC/DC
85 – 264 V AC
￫Page 2/33
Labeling with convenience
5
All button plates, indicator lights and
additional button labels from the
RMQ-Titan range can be laser
inscribed with any inscription and
symbol as required.
Download:
www.moeller.net/de/support,
Keyword: “Labeleditor”
Surface mounting enclosure
6
Surface mounting enclosures IP67
up to 6 mounting locations
Surface mounting enclosures IP55
up to 12 mounting locations
Flush mounting panel, IP54, up to
6 mounting locations
Shrouds IP40 for flush mounting
panels
￫Page 2/45
Telescopic clip
7
For mounting depth compensation
when rear mounting devices in CI
enclosures, CI-K enclosures and
cabinets
￫Page 2/48
Centring adapter
8
For centring of actuator and
indicator elements when using
telescopic clip
￫Page 2/48
IVS top-hat rail adapter
9
for fitting directly onto IEC/EN 60175
mounting rail
￫Page 2/49
Label mounts
10
For insert labels
Colour: black
Insert labels, aluminium-colored,
with and without inscription, can be
engraved
￫Page 2/35
Acoustic device
11
Protection type IP40
without buzzer
￫Page 2/27
Buzzer
12
Continuous tone, pulsed tone
18 - 30 V AC/DC
￫Page 2/27
Potentiometer
13
Resistance values
from 470 k
Ω - 1 MΩ
3 individual connections
With screw terminals
￫Page 2/27
Bezels
14
• Silver
• Black
• 24 carat gold can only be ordered
via M22-Combination
￫Page 2/48
Indicator lights
15
Flat and conical designs
Colours: white, green, red, yellow,
blue
￫Page 2/26
Key-operated buttons
16
2 and 3 positions
Programmable maintained/momen-
tary function and key withdraw
Suitable for master key systems
￫Page 2/21
Selector switch actuators
17
2 and 3 positions
With rotary head, thumb-grip
Programmable maintained/momen-
tary function
Illuminated selector switch actua-
tors with transparent thumb-grip
Colours: white, green, red, yellow,
blue
￫Page 2/20
Button plates/Button lenses
18
Laser inscription for pushbutton
actuators and mushroom-headed
pushbutton
Button lenses for illuminated push-
button actuators and indicator lights,
flat
With standard texts and symbols or
with custom labelling
￫Page 2/36
Pushbutton actuators
19
Momentary and maintained
Flat and extended
with and without guard ring
Mushroom-headed pushbutton
Double actuators
Colours: white, green, red, yellow,
blue, black
Illuminated pushbutton actuators
Colours: white, green, red, yellow,
blue
￫Page 2/17
Emergency stop pushbuttons/
Emergency switching off pushbut-
tons
20
Tamper-proof according to
ISO 13850/EN 418
Can be secured by sealable shroud
Additional labels, with and without
inscription
￫Page 2/8
Joystick
21
4 positions
￫Page 2/24
4-way pushbutton
22
4 positions
Pushbutton actuators, momentary
￫Page 2/24
Accessories devices
23
￫Page 2/48
Product Features
• Order with the designation M22-COMBINA-
TION￫Page 2/6 and the suffix M22-ATEX
or FAK-COMBINATION- ￫Page 2/78
with the suffix FAK-ATEX￫Page 2/45
• Snap-fitting modular system
• bezel silver, black or gold
• Mounting diameter: 22.3 mm
• Minimum grid dimension: 30 x 40 mm
• Protection type: minimum IP66
• Up to 6 contacts per mounting location
• For switching differing potentials
• Approved throughout the world
