RMQ-Titan pilot devices
Pushbuttons
2010 CA08103002Z-EN
2/17
Pushbuttons
Bezel: silver Bezel: black
Button plate Part no.
Article no.
Price
See price
list
Std. pack Part no.
Article no.
Price
See price
list
Std. pack Notes
Pushbutton actuators IP67, IP69K
￫Engineering
Bezel gold-plated￫Page 2/48
Actuator flat
momentary
M22-D-S
216590
10 off M22S-D-S
216591
10 off –
M22-D-W
216592
M22S-D-W
216593
–
M22-D-R
216594
M22S-D-R
216595
–
M22-D-G
216596
M22S-D-G
216597
–
M22-D-Y
216598
M22S-D-Y
216599
–
M22-D-B
216600
M22S-D-B
216601
–
M22-D-GR
132671
M22S-D-GR
132672
–
– M22-D-X
216602
M22S-D-X
216604
–
– M22-D-X-GVP
216603
50 off –
M22-D-R-X0
216605
10 off M22S-D-R-X0
216606
10 off –
M22-D-G-X1
216607
M22S-D-G-X1
216608
–
M22-D-S-X0
216609
M22S-D-S-X0
216610
–
M22-D-W-X1
216611
M22S-D-W-X1
216612
–
Actuator flat,
maintained
M22-DR-S
216613
5 off M22S-DR-S
216614
5 off Programmable
maintained/momentary
pushbutton function
M22-DR-W
216615
M22S-DR-W
216616
M22-DR-R
216617
M22S-DR-R
216618
M22-DR-G
216619
M22S-DR-G
216620
M22-DR-Y
216621
M22S-DR-Y
216622
M22-DR-B
216623
M22S-DR-B
216624
– M22-DR-X
216625
M22S-DR-X
216627
– M22-DR-X-GVP
216626
50 off
M22-DR-R-X0
216628
5 off M22S-DR-R-X0
216629
5 off
M22-DR-G-X1
216630
M22S-DR-G-X1
216631
M22-DR-S-X0
216632
M22S-DR-S-X0
216633
M22-DR-W-X1
216634
M22S-DR-W-X1
216635
Information relevant for export to North America Product Standards IEC/EN 60947-5; UL 508; CSA-C22.2 No. 14-05; CSA-C22.2 No. 94-91; CE marking
UL File No. E29184
UL CCN NKCR
CSA File No. 012528
CSA Class No. 3211-03
NA Certification UL Listed, CSA certified
Degree of Protection UL/CSA Type 3R, 4X, 12, 13
ATEX
≈ 3 mm
M22-DR...
O I O I
M22-D...
M22?D(R)P… HPL02017EN
